Max. 5Megapixel (2592 x 1944) resolution
3.2~10mm(3.1x) motorized varifocal lens
0.15Lux (Color), 0Lux (B/W, IR LED on)
Max. 30fps@5MP (H.265 / H.264)
H.265, H.264, MJPEG codec support, Multiple streaming
Day & Night, WDR (120dB)
Tampering, Motion detection, Defocus detection
Micro SD / SDHC / SDXC memory slot (Max. 128GB)
Hallway view, WiseStream II support
IR Viewable length 30m
IP66, IK10, PoE
| Performance |
|---|
| Languages support |
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish |
| Alarm input/output |
Yes |
| Day/night mode |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Outdoor |
| Type |
IP security camera |
| Design |
|---|
| IK code |
IK10 |
| International Protection (IP) code |
IP66 |
| Protection features |
Vandal proof |
| Housing material |
Aluminium |
| LED indicators |
Yes |
| Product colour |
White |
| Mounting type |
Ceiling |
| Form factor |
Dome |
| Camera |
|---|
| Adjustment shutter speed |
Manual |
| Camera shutter type |
Electronic |
| White balance |
ATW, AWC, Indoor, Manual, Outdoor |
| Pan range |
0 - 350° |
| Tilt angle range |
0 - 67° |
| Lens viewing angle, diagonal |
133.1° |
| Lens viewing angle, vertical |
72.3° |
| Lens viewing angle, horizontal |
100.3° |
| Minimum illumination |
0.15 lx |
| Image sensor |
|---|
| Number of effective pixels (H x V) |
2592 x 1944 pixels |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") |
| Sensor type |
CMOS |
| Lens system |
|---|
| Maximum aperture number |
1.6 |
| Focal length range |
3.2 - 10 mm |
| Night vision |
|---|
| LED type |
IR |
| Night vision distance |
30 m |
| Night vision |
Yes |
| Video |
|---|
| Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Flip & mirror |
Yes |
| Privacy masking |
Yes |
| Back Light Compensation (BLC) |
Yes |
| Gain control type |
Manual |
| Noise reduction |
Yes |
| Video streaming |
Yes |
| Supported graphics resolutions |
640 x 360, 640 x 480 (VGA), 720 x 480, 768 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 960, 1920 x 1080 (HD 1080), 2592 x 1944 |
| Video compression formats |
H.264, H.265, M-JPEG |
| Total megapixels |
5 MP |
| Maximum resolution |
2592 x 1944 pixels |
| Network |
|---|
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Storage |
|---|
| Card reader integrated |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
|---|
| Video motion detection |
Yes |
| Active tampering alarm |
Yes |
| IP address filtering |
Yes |
| Alert notification type |
E-mail |
| Power |
|---|
| Power consumption (max) |
8.9 W |
| Power source type |
PoE |
| System requirements |
|---|
| Mac operating systems supported |
Yes |
| Windows operating systems supported |
Yes |
| Weight & dimensions |
|---|
| Diameter |
13.7 cm |
| Height |
106.1 mm |
