PoE Switches for Your Ultra Convenience
5-Port 10/100Mbps Desktop Switch with 4-Port PoE
Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).
Intelligent Power Management
When total power consumption excels 58W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.
Sturdy Metal Casing
Sturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.
| Management features |
|---|
| Switch type |
Unmanaged |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports type |
Fast Ethernet (10/100) |
| Basic switching RJ-45 Ethernet ports quantity |
5 |
| Network |
|---|
| MAC address auto-aging supported |
Yes |
| Auto MDI/MDI-X |
Yes |
| MAC address auto-learning supported |
Yes |
| Flow control support |
Yes |
| Auto-negotiation |
Yes |
| Full duplex |
Yes |
| Half duplex |
Yes |
| Cable types supported |
Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 100BASE-T |
| 10G support |
No |
| Networking standards |
IEEE 802.3af, IEEE 802.3x |
| Data transmission |
|---|
| Jumbo frames |
2000 |
| Jumbo frames support |
Yes |
| Store-and-forward |
Yes |
| Forwarding rate |
0.744 Mpps |
| Switching capacity |
1 Gbit/s |
| MAC address table |
2000 entries |
| Design |
|---|
| LED indicators |
Yes |
| Product colour |
Black |
| Stackable |
No |
| Rack mounting |
No |
| Performance |
|---|
| Fanless |
Yes |
| Maximum cable length |
100 m |
| Power |
|---|
| Power consumption (max) |
74 W |
| Input current |
1.31 A |
| DC input voltage |
53.5 V |
| AC input frequency |
50 Hz |
| AC input voltage |
220 V |
| Power supply included |
No |
| Power source |
DC/PoE |
| Power over Ethernet (PoE) |
|---|
| Total Power over Ethernet (PoE) budget |
67 W |
| Power over Ethernet plus (PoE+) ports quantity |
4 |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Heat dissipation |
252.34 BTU/h |
| Storage relative humidity (H-H) |
5 - 90% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Height |
25 mm |
| Depth |
98 mm |
| Width |
99.8 mm |
| Packaging content |
|---|
| User guide |
Yes |
| Packaging data |
|---|
| Package weight |
760 g |
| Package height |
121 mm |
| Package depth |
196 mm |
| Package width |
131 mm |
| Package type |
Box |
| AC adapter included |
Yes |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Certificates |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
