Finisar® FTL410QE2C compatible 40GBase-SR QSFP+ transceiver (MMF, 850nm, 150m, MPO, DOM). A 100% Finisar® compatible QSFP+ transceiver that operates at 850nm over multi-mode fiber, with a maximum reach of 150m connected via a MPO connector. This Finisar® QSFP+ transceiver is 100% compliant with its designed networking application, and is factory programmed with Finisar® specific configuration data required for seamless networking integration. This QSFP+ transceiver will initialize and perform identically to Finisar's transceiver and is built to meet or exceed Finisar's specifications, and comply with MSA (Multi-Source Agreement) standards. The actual part shipped may have a different part number, but will be functionally identical and 100% compatible. Trade Agreements Act (TAA) versions of this part are available.
| Performance |
|---|
| Duplex system |
Full |
| Wavelength |
850 nm |
| Maximum transfer distance |
150 m |
| SFP transceiver standard |
SR |
| Fiber optic connector |
MPO |
| Multi-mode fiber (MMF) supported |
Yes |
| Interface type |
QSFP+ |
| Maximum data transfer rate |
40000 Mbit/s |
| SFP transceiver type |
Fiber optic |
| Features |
|---|
| Compatible products |
Finisar |
| Hot-Plug support |
Yes |
| Power |
|---|
| Power consumption (typical) |
1.5 W |
| Input voltage |
3.3 V |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 85% |
| Storage temperature (T-T) |
-20 - 85 °C |
| Operating temperature (T-T) |
0 - 70 °C |
| Weight & dimensions |
|---|
| Weight |
109 g |
| Height |
13.5 mm |
| Depth |
71.1 mm |
| Width |
18.8 mm |
| Packaging data |
|---|
| Package weight |
200 g |
| Package height |
30.5 mm |
| Package depth |
121 mm |
| Package width |
69.8 mm |
