Enhanced Gamma Correction
Selectable gamma curves visually optimise different kinds of images. The AG Neovo specialised image settings enhance colour, brightness, sharpness and contrast ratio, allowing the X-Series to improve the light, shadows and colour balance of videos.
Versatility, Productivity and Compatibility
Visualize critical data and engage with multiple video sources and PC applications with versatile connectivity options, including DisplayPort and HDMI, and PIP/PBP to increase productivity and efficiency. Selectable aspect ratio and zoom functions provide compatibility with different video sources.
High Reliability
Designed for 24/7 operation, these durable metal-housed displays protected with NeoV™ Optical Glass take advantage of superior components to ensure a long product lifetime.
| Display |
|---|
| 3D |
No |
| Vertical scan range |
50 - 85 Hz |
| Horizontal scan range |
15 - 81 kHz |
| Pixel pitch |
0.294 x 0.294 mm |
| Display number of colours |
16.78 million colours |
| Viewing angle, vertical |
160° |
| Viewing angle, horizontal |
170° |
| Contrast ratio (dynamic) |
20000000:1 |
| Contrast ratio (typical) |
1000:1 |
| Supported graphics resolutions |
1280 x 1024 (SXGA) |
| Screen shape |
Flat |
| Response time |
3 ms |
| Display brightness (typical) |
250 cd/m² |
| Backlight type |
LED |
| Panel type |
TFT |
| HD type |
SXGA |
| Touchscreen |
No |
| Display technology |
LED |
| Native aspect ratio |
5:4 |
| Display resolution |
1280 x 1024 pixels |
| Display diagonal |
48.3 cm (19") |
| Performance |
|---|
| Flicker-free technology |
Yes |
| AMD FreeSync |
No |
| NVIDIA G-SYNC |
No |
| Multimedia |
|---|
| Built-in camera |
No |
| RMS rated power |
2 W |
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product colour |
Black |
| Market positioning |
Medical |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| Audio input |
Yes |
| DisplayPort version |
1.2a |
| DisplayPorts quantity |
1 |
| HDMI version |
1.4 |
| HDMI ports quantity |
1 |
| HDMI |
Yes |
| DVI-D ports quantity |
1 |
| DVI port |
Yes |
| VGA (D-Sub) ports quantity |
1 |
| Built-in USB hub |
No |
| Network |
|---|
| Ethernet LAN |
No |
| Bluetooth |
No |
| Wi-Fi |
No |
| Ergonomics |
|---|
| Picture-in-Picture |
Yes |
| Tilt angle range |
0 - 20° |
| Tilt adjustment |
Yes |
| Height adjustment |
No |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Panel mounting interface |
75 x 75,100 x 100 mm |
| VESA mounting |
Yes |
| Power |
|---|
| European Product Registry for Energy Labelling (EPREL) code |
444576 |
| Energy efficiency scale |
A to G |
| Power consumption (off) |
0.5 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
15 W |
| Energy consumption (SDR) per 1000 hours |
14 kWh |
| Energy efficiency class (SDR) |
E |
| Operational conditions |
|---|
| Non-operating altitude |
0 - 12192 m |
| Operating altitude |
0 - 3000 m |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight (without stand) |
6 kg |
| Height (without stand) |
420.2 mm |
| Depth (without stand) |
175 mm |
| Width (without stand) |
445.4 mm |
| Weight (with stand) |
6.8 kg |
| Packaging data |
|---|
| Package type |
Box |
| Package weight |
8.4 kg |
| Package height |
526 mm |
| Package depth |
225 mm |
| Package width |
552 mm |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Cables included |
AC, Audio (3.5mm), VGA |
| Stand included |
Yes |
| Other features |
|---|
| Certification |
CB, CE, WEEE, REACH, EuP/Erp |
| Compliance certificates |
RoHS |
| AC adapter included |
Yes |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
