Precision-engineered for graphics excellence with hardware-calibrated precision (Delta E<2), calman ready calibration, and UHD Nano IPS display
The AOC Graphic Pro U32U3CV delivers outstanding color accuracy right out of the box, courtesy of its hardware calibration achieving Delta E<2 (sRGB). Easily adjust settings for peak performance with the Calman Ready feature. With a remarkable 98% coverage of the DCI P3, 100% of the sRGB and 100% of the Rec 709 color space, it's tailor-made for graphic and photo editing, offering superior quality compared to standard monitors. Its Delta E < 2 accuracy ensures precise color rendering that exceeds human eye perception. Enhanced with a UHD Nano IPS display, Vesa DisplayHDR 400, USB-C docking station, and sleek design, it stands out as the ultimate choice for professionals.
| Display |
|---|
| sRGB coverage (typical) |
135.3% |
| Colour gamut |
98% |
| Colour gamut standard |
DCI-P3 |
| Surface hardness |
3H |
| Haze rate |
25% |
| DDC/CI |
Yes |
| High Dynamic Range (HDR) technology |
DisplayHDR 400 |
| High Dynamic Range (HDR) supported |
Yes |
| Display diagonal (metric) |
80 cm |
| Digital vertical frequency |
23 - 75 Hz |
| Digital horizontal frequency |
30 - 140 kHz |
| Viewable size, vertical |
39.2 cm |
| Viewable size, horizontal |
69.7 cm |
| Vertical scan range |
23 - 75 Hz |
| Horizontal scan range |
30 - 140 kHz |
| Pixel density |
140 ppi |
| Pixel pitch |
0.18159 x 0.18159 mm |
| Display number of colours |
1.073 billion colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Maximum refresh rate |
60 Hz |
| Contrast ratio (dynamic) |
50000000:1 |
| Contrast ratio (typical) |
1000:1 |
| Screen shape |
Flat |
| Anti-glare screen |
Yes |
| Response time measurement type |
GTG (Gray to Gray) |
| Response time |
4 ms |
| Display brightness (typical) |
400 cd/m² |
| Backlight type |
W-LED |
| LED backlight |
Yes |
| Panel type |
Nano IPS |
| HD type |
4K Ultra HD |
| Touchscreen |
No |
| Display technology |
LCD |
| Native aspect ratio |
16:9 |
| Display resolution |
3840 x 2160 pixels |
| Display diagonal |
80 cm (31.5") |
| Performance |
|---|
| Flicker-free technology |
Yes |
| VESA Adaptive Sync support |
Yes |
| Fast charging |
Yes |
| Multimedia |
|---|
| Built-in camera |
No |
| RMS rated power |
6 W |
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Feet colour |
Grey |
| Detachable stand |
Yes |
| Front bezel colour |
Black/Silver |
| Frameless design |
Yes |
| Product colour |
Black |
| Market positioning |
Graphics design |
| Ports & interfaces |
|---|
| AC (power) in |
Yes |
| HDCP version |
2.2 |
| HDCP |
Yes |
| Built-in KVM switch |
Yes |
| Headphone outputs |
1 |
| Headphone out |
Yes |
| Audio output |
Yes |
| DisplayPort version |
1.4 |
| DisplayPorts quantity |
1 |
| HDMI version |
2.0 |
| HDMI ports quantity |
2 |
| HDMI |
Yes |
| USB Power Delivery up to |
96 W |
| USB Power Delivery (USB PD) |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Type-C downstream ports quantity |
1 |
| USB Type-A downstream ports quantity |
4 |
| Number of upstream ports |
2 |
| USB upstream port type |
USB Type-C |
| USB hub version |
3.2 Gen 2 (3.1 Gen 2) |
| Built-in USB hub |
Yes |
| Ergonomics |
|---|
| Plug and Play |
Yes |
| Picture-in-Picture |
Yes |
| Tilt angle range |
-6.5 - 23° |
| Tilt adjustment |
Yes |
| Swivel angle range |
-15 - 15° |
| Swivelling |
Yes |
| Pivot angle |
-90 - 90° |
| Pivot |
Yes |
| Adjustable height (max) |
15 cm |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| VESA mounting |
Yes |
| Power |
|---|
| Energy efficiency scale |
A to G |
| Power supply type |
Internal |
| Input current |
3 A |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power consumption (off) |
0.3 W |
| Power consumption (max) |
215 W |
| Power consumption (standby) |
0.3 W |
| Power consumption (typical) |
30.37 W |
| Energy consumption (HDR) per 1000 hours |
56 kWh |
| Energy consumption (SDR) per 1000 hours |
32 kWh |
| Energy efficiency class (HDR) |
G |
| Energy efficiency class (SDR) |
F |
| Operational conditions |
|---|
| Non-operating altitude |
0 - 12192 m |
| Operating altitude |
0 - 5000 m |
| Storage relative humidity (H-H) |
5 - 93% |
| Operating relative humidity (H-H) |
10 - 85% |
| Storage temperature (T-T) |
-25 - 55 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight (without stand) |
6.34 kg |
| Weight (with stand) |
8.46 kg |
| Height (with stand) |
609.3 mm |
| Depth (with stand) |
258.6 mm |
| Width (with stand) |
714.4 mm |
| Packaging data |
|---|
| Package type |
Box |
| Package weight |
12.6 kg |
| Packaging content |
|---|
| Power cable length |
1.8 m |
| HDMI cable length |
1.8 m |
| DisplayPort cable length |
1.8 m |
| Quick start guide |
Yes |
| Cables included |
AC, HDMI, DisplayPort, USB Type-C |
| Stand included |
Yes |
| Sustainability |
|---|
| Doesn't contain |
Mercury, PVC/BFR |
| Sustainability certificates |
EPEAT Gold, TCO |
| General |
|---|
| Product family |
U3 |
| Other features |
|---|
| Certification |
WEEE,REACH compliant,RoHs compliant,HF,CB,TUV-GS-Mark,EAC,FCC,Microsoft WHQL |
| Mean time between failures (MTBF) |
30000 h |
| Warranty period |
3 year(s) |
| Compliance certificates |
CE |
| Bezel thickness type |
Frameless |
| Local dimming |
Yes |
| Low input lag |
No |
