PCIe 5.0 Ready
Faster storage, graphics and networking capabilities
PCI Express® (PCIe®) 5.0 delivers 32GT/s bandwidth, which is twice the speed of PCIe 4.0, and offers lower power consumption, better land scalability and backwards compatibility. ASUS servers are PCIe 5.0 ready with scalability design to satisfy the increasing workloads for modern data center.
AMD EPYC™ 9004 Series Processors
The 9004 Series EPYC CPUs amplifies the AMD history of x86 architecture innovations and record-breaking performance with next generation 5nm technology as well as introducing support for high performant DDR5 DIMMs and fast PCIe® Gen 5 I/O. EPYC 9004 CPUs support 12 memory channels with 2 DIMMs/channel capability, delivering the resources needed for memory hungry AI, ML, HPC, and large in-memory computations.
| Processor |
|---|
| Compatible processor series |
AMD EPYC 9004 |
| Number of processors supported |
1 |
| Processor family |
AMD EPYC |
| Processor manufacturer |
AMD |
| Processor socket |
Socket SP5 |
| Memory |
|---|
| Supported RDIMM clock speeds |
4400,4800,4000,3600 MHz |
| Maximum internal memory |
6.14 TB |
| Supported DIMM module capacities |
128GB, 64GB, 32GB, 16GB, 256GB |
| Supported memory types |
DDR5-SDRAM |
| Number of DIMM slots |
24 |
| Storage |
|---|
| SSD form factor |
M.2 |
| Supported storage drive types |
HDD & SSD |
| Storage drive sizes supported |
2.5,M.2 |
| Number of 2.5" bays |
12 |
| Hot-swap HDD bays |
Yes |
| Number of storage drives supported |
14 |
| Network |
|---|
| LAN controller |
Intel® I350-AM2 |
| Ethernet LAN |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Ports & interfaces |
|---|
| COM ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
| IPMI LAN (RJ-45) port |
Yes |
| Ethernet LAN (RJ-45) ports |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Expansion slots |
|---|
| PCI Express slots version |
5.0 |
| Technical details |
|---|
| Compliance certificates |
BSMI, CE, CB, RCM, Federal Communications Commission (FCC) |
| Design |
|---|
| On/off switch |
Yes |
| LED indicators |
Yes |
| Product colour |
Grey |
| Chassis type |
Rack (1U) |
| Power |
|---|
| Redundant power supply (RPS) support |
Yes |
| Power supply |
1600 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
20 - 90% |
| Weight & dimensions |
|---|
| Weight |
14.2 kg |
| Width |
449 mm |
| Depth |
842.5 mm |
| Height |
43.9 mm |
| Packaging data |
|---|
| Package weight |
19.2 kg |
