Mechanised endurance. Battlefield brilliance.
Featuring an AMD Ryzen™ 5 7535HS/H Mobile Processor, an NVIDIA® GeForce RTX™ 2050 Laptop GPU, and a dedicated MUX Switch with NVIDIA® Advanced Optimus — prepare to crank the graphics settings in all the latest games. All that horsepower drives a gorgeous FHD 144 Hz panel with G-SYNC support, ensuring buttery smooth motion on screen. Keep your cool in the heat of extended gaming sessions with dual 84-blade Arc Flow Fans™ and a network of five heat pipes that efficiently wick heat out of the chassis.
| Design |
|---|
| Introduction year |
2021 |
| Market positioning |
Gaming |
| Form factor |
Clamshell |
| Colour name |
Graphite Black |
| Product colour |
Black |
| Product type |
Laptop |
| Display |
|---|
| Maximum refresh rate |
144 Hz |
| RGB colour space |
NTSC |
| Colour gamut |
45% |
| Display brightness |
250 cd/m² |
| Anti-glare screen |
Yes |
| Native aspect ratio |
16:9 |
| Panel type |
IPS |
| HD type |
Full HD |
| Touchscreen |
No |
| Display resolution |
1920 x 1080 pixels |
| Display diagonal |
43.9 cm (17.3") |
| Processor |
|---|
| Processor cache type |
L3 |
| Processor cache |
16 MB |
| Processor frequency |
3.3 GHz |
| Processor boost frequency |
4.55 GHz |
| Processor cores |
6 |
| Processor model |
7535HS |
| Processor family |
AMD Ryzen™ 5 |
| Processor manufacturer |
AMD |
| Memory |
|---|
| Maximum internal memory |
32 GB |
| Memory slots |
2x SO-DIMM |
| Memory layout (slots x size) |
2 x 8 GB |
| Memory clock speed |
4800 MHz |
| Memory form factor |
SO-DIMM |
| Internal memory type |
DDR5-SDRAM |
| Internal memory |
16 GB |
| Storage |
|---|
| Optical drive type |
No |
| SSD form factor |
M.2 |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD capacity |
512 GB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
512 GB |
| Storage media |
SSD |
| Total storage capacity |
512 GB |
| Graphics |
|---|
| On-board graphics card model |
AMD Radeon 660M |
| Discrete graphics memory type |
GDDR5 |
| Discrete graphics card memory |
4 GB |
| Discrete graphics card model |
NVIDIA GeForce RTX 2050 |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics card |
Yes |
| On-board graphics card |
Yes |
| Audio |
|---|
| Built-in microphone |
Yes |
| Speaker power |
2 W |
| Number of built-in speakers |
2 |
| Camera |
|---|
| Front camera resolution |
1280 x 720 pixels |
| Front camera HD type |
HD |
| Front camera |
Yes |
| Network |
|---|
| Bluetooth version |
5.3 |
| Bluetooth |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| Antenna type |
2x2 |
| Wi-Fi standards |
Wi-Fi 6 (802.11ax) |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Mobile network connection |
No |
| Ports & interfaces |
|---|
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Power adapter barrel connector |
6.0 mm |
| Combo headphone/mic port |
Yes |
| HDMI version |
2.1 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| Keyboard |
|---|
| Keyboard backlit colour |
RGB |
| Keyboard backlit zone |
1-zone RGB |
| Numeric keypad |
Yes |
| Keyboard backlit |
Yes |
| Pointing device |
Touchpad |
| Software |
|---|
| Operating system architecture |
64-bit |
| Battery |
|---|
| Battery capacity |
48 Wh |
| Number of battery cells |
3 |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Power |
|---|
| USB Type-C charging port |
No |
| AC adapter output voltage |
20 V |
| AC adapter output current |
7.5 A |
| AC adapter input voltage |
100 - 240 V |
| AC adapter frequency |
50 - 60 Hz |
| AC adapter power |
150 W |
| Security |
|---|
| Password protection type |
BIOS, User |
| Password protection |
Yes |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Weight & dimensions |
|---|
| Height (rear) |
2.48 cm |
| Height (front) |
2.33 cm |
| Depth |
269 mm |
| Width |
399 mm |
| Weight |
2.6 kg |
| General |
|---|
| Product family |
TUF Gaming |
| Product series |
A17 |
| Packaging content |
|---|
| AC adapter included |
Yes |
