Sleek and portable design
ASUS ZenScreen™ is ideal for life on the road. This sleek portable display is light weight and has a slim profile, so it fits easily in any travel bag and is ready for productivity, anytime and anywhere.
One cable is all you need
ZenScreen MB166CR uses a single USB Type-C* connection for both power and video transmission from your host device. This means you have less cables to work with, so you get a neater work area.
Designed with Versatility
A 360° detachable kickstand allow you to screw-in with ease on the rear tripod socket, enabling easy tilt adjustments in either portrait or landscape mode.
With the 360° kickstand design you can even put it on a tabletop mount with ease.
| Display |
|---|
| Digital vertical frequency |
60 - 60 Hz |
| Digital horizontal frequency |
24 - 83 kHz |
| Viewable size, vertical |
19.4 cm |
| Viewable size, horizontal |
34.4 cm |
| Pixel pitch |
0.179 x 0.179 mm |
| Display number of colours |
262000 colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Maximum refresh rate |
60 Hz |
| Contrast ratio (typical) |
800:1 |
| Screen shape |
Flat |
| Anti-glare screen |
Yes |
| Response time |
5 ms |
| Display brightness (typical) |
250 cd/m² |
| Backlight type |
LED |
| Panel type |
IPS |
| HD type |
Full HD |
| Display technology |
LCD |
| Native aspect ratio |
16:9 |
| Display resolution |
1920 x 1080 pixels |
| Display diagonal |
39.6 cm (15.6") |
| Performance |
|---|
| Game mode |
Yes |
| Low Blue Light technology |
Yes |
| Flicker-free technology |
Yes |
| Multimedia |
|---|
| Built-in camera |
No |
| Built-in speaker(s) |
No |
| Design |
|---|
| Product colour |
Black |
| Market positioning |
Home |
| Ports & interfaces |
|---|
| HDCP |
Yes |
| Headphone out |
No |
| HDMI |
No |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Type-C downstream ports quantity |
1 |
| Ergonomics |
|---|
| Height adjustment |
No |
| Cable lock slot |
No |
| Power |
|---|
| European Product Registry for Energy Labelling (EPREL) code |
1906388 |
| Energy efficiency scale |
A to G |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power consumption (PowerSave) |
0.5 W |
| Power consumption (off) |
0.3 W |
| Power consumption (typical) |
5.24 W |
| Energy consumption (SDR) per 1000 hours |
6 kWh |
| Energy efficiency class (HDR) |
Not available |
| Energy efficiency class (SDR) |
B |
| Weight & dimensions |
|---|
| Weight (without stand) |
780 g |
| Height (without stand) |
225.6 mm |
| Depth (without stand) |
11.8 mm |
| Width (without stand) |
360.1 mm |
| Packaging data |
|---|
| Package type |
Box |
| Package weight |
1.7 kg |
| Package height |
76 mm |
| Package depth |
290 mm |
| Package width |
434 mm |
| General |
|---|
| Product family |
ZenScreen |
| Other features |
|---|
| Brand specific technologies |
SPLENDID |
