Without connecting any external processing device, the built-in
Android™ OS allows you to access files, display contents, and start presentations directly on the display.
Edit, manage, and customise content through the X-Sign Content Management Software by
using the 150+ templates available; with the X-Sign Broadcast, you can deliver instant announcement to all your BenQ’s displays.
Combined with DMS Cloud and DMS Local, BenQ’s Device Management Solution helps you easily manage
all your BenQ displays at the same time and maximise the productivity for your workplace.
With the pre-installed TeamViewer Meeting, you can start video meetings with a simple click. The ST02S series is perfect for video conferencing solutions.
| Display |
|---|
| RGB colour space |
NTSC |
| Panel life |
30000 h |
| Display diagonal (metric) |
217 cm |
| Active display area (W x H) |
1895 x 1066 mm |
| Contrast ratio (typical) |
1200:1 |
| Response time |
8 ms |
| Native aspect ratio |
16:9 |
| Touchscreen |
No |
| HD type |
4K Ultra HD |
| Display brightness |
400 cd/m² |
| Display resolution |
3840 x 2160 pixels |
| LED backlighting type |
Direct-LED |
| Panel type |
ADS |
| Display technology |
LED |
| Display diagonal |
2.18 m (86") |
| Ports & interfaces |
|---|
| PC Audio in |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN |
Yes |
| USB version |
2.0 |
| USB ports quantity |
2 |
| USB port |
Yes |
| VGA (D-Sub) input ports |
1 |
| DVI-D ports quantity |
1 |
| DVI port |
Yes |
| HDMI version |
2.0 |
| HDMI ports quantity |
3 |
| Audio |
|---|
| RMS rated power |
20 W |
| Number of built-in speakers |
2 |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Panel mounting interface |
600 x 400 mm |
| VESA mounting |
Yes |
| Screen shape |
Flat |
| Placement supported |
Indoor |
| Product colour |
Black |
| Product design |
Digital signage flat panel |
| Performance |
|---|
| Operating hours (hours/days) |
18/7 |
| Purpose |
Universal |
| Power |
|---|
| AC input frequency |
50 - 60 Hz |
| AC input voltage |
100-240 V |
| Energy consumption (SDR) per 1000 hours |
327 kWh |
| Energy efficiency class (SDR) |
G |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
317 W |
| Computer system |
|---|
| Operating system installed |
Android 8.0 |
| Internal storage capacity |
16 GB |
| Internal memory |
3 GB |
| Built-in processor |
Yes |
| Computer system |
Yes |
| Weight & dimensions |
|---|
| Display weight |
53 kg |
| Display height |
1100 mm |
| Display depth |
79.4 mm |
| Display width |
1929 mm |
| Packaging data |
|---|
| Package volume |
64000 cm³ |
| Package height |
1321 mm |
| Package depth |
2130 mm |
| Package width |
248 mm |
| Packaging content |
|---|
| Cables included |
HDMI |
| Remote control included |
Yes |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
10 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Operating temperature (T-T) |
0 - 40 °C |
| Logistics data |
|---|
| Harmonized System (HS) code |
8528529100 |
| Products per pallet |
5 pc(s) |
| Country of origin |
China |
