With high-performance wired and wireless connectivity and dedicated user touchscreen. Ideal for high-volume, secure batch scanning for collaborative and complex workflows.
For uninterrupted high-volume, batch scanning. With the simplicity of one-touch scanning, securely capture, send and receive business documents with ease, whether they're at home or in the office.
Fast and reliable
With an in-built ultrasonic multifeed to eliminate misfeeds, the ADS-4900W has the largest sheet ADF capacity (100 sheets) and is the fastest in the range, scanning up to 60 pages per minute, or one every second. The separation switch enables very thick and thin documents, plastic cards and crumpled paper to smoothly feed through with ease.
Simple and intuitive
Set up a dedicated user interface with one-touch scanning and the ability to add up to 56 shortcuts to frequently used destinations. You can also use an optional external cardreader to make the scanning process even easier. Just tap the card and add your documents into the ADF to automatically and securely capture the information on the page.
Advanced connectivity
With 5GHz wireless connectivity, network, USB3.0 and USB host, you can securely scan documents and share with colleagues.
Advanced image capture and processing
Effortless and impressive image capture and processing - from easily referencing and locating scanned pages with the digital imprinter, to optimising image quality through the automatic vertical streaks and moiré reduction tools.
The document separation functionality also automatically detects and removes any scanned blank pages, thus reducing file sizes and document preparation time.
Brother ScanEssentials
Our ScanEssentials software provides you with additional features which you can tailor to your business. For added security, you can set up passwords and protect your workflows, with the option to save your documents in a variety of formats.
The metadata function can also read barcodes or specific strings of text to easily facilitate the separation and file naming of documents.
Industry recognised software
Increase post-scanning productivity with industry recognised software including Kofax and Newsoft, available as standard with device.
| Scanning |
|---|
| Duplex ADF scan speed (b/w, A4) |
120 ipm |
| Duplex ADF scan speed (colour, A4) |
120 ipm |
| ADF scan speed (colour, A4) |
60 ppm |
| ADF scan speed (b/w, A4) |
60 ppm |
| Greyscale levels |
256 |
| Output greyscale depth |
8 bit |
| Output colour depth |
24 bit |
| Input colour depth |
48 bit |
| Duplex scanning |
Yes |
| Colour scanning |
Yes |
| Enhanced scan resolution |
1200 x 1200 DPI |
| Optical scanning resolution |
600 x 600 DPI |
| Maximum scan size |
215.9 x 355.6 mm |
| Design |
|---|
| Control type |
Touch |
| Colour display |
Yes |
| Touchscreen |
Yes |
| Display diagonal |
10.9 cm (4.3") |
| Display |
LCD |
| Product colour |
Black, White |
| Built-in display |
Yes |
| Scanner type |
ADF + Sheet-fed scanner |
| Performance |
|---|
| Scanning noise level |
62 dB |
| Scan drivers |
ISIS, SANE, TWAIN, WIA |
| Ultrasonic sensor |
Yes |
| Scan to |
E-mail Server, FTP, HTTP, PC, SMB |
| Maximum duty cycle |
180000 pages per month |
| Daily duty cycle (max) |
9000 pages |
| Scan file formats |
JPEG, PDF, TIFF |
| Light source |
LED |
| Sensor type |
Dual CIS |
| Input capacity |
|---|
| Auto document feeder (ADF) input capacity |
100 sheets |
| Paper handling |
|---|
| Maximum scan length |
5 m |
| Maximum scan width |
21.6 cm |
| Paper tray media weight |
25 - 413 g/m² |
| Card thickness (max) |
1.32 mm |
| Media thickness (min) |
0.08 mm |
| Long-paper mode |
Yes |
| Scanning media types supported |
Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| Maximum ISO A-series paper size |
A4 |
| Ports & interfaces |
|---|
| USB version |
2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB port |
Yes |
| Network |
|---|
| IPv6 support |
Yes |
| Supported network protocols (IPv6) |
RA, DNS Resolver, mDNS, LLMNR responder, Web Services(Scan), SNTP Client, HTTP/HTTPS server, ICMPv6 |
| Supported network protocols (IPv4) |
DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP |
| Security algorithms |
AES, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, TLS, WEP, WPA-PSK, WPA2-AES, WPA2-PSK, WPA3 |
| Ethernet LAN |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Wi-Fi |
Yes |
| Power |
|---|
| Auto power off |
Yes |
| Output voltage |
24 V |
| Output current |
1.9 A |
| Power consumption (sleep) |
1.7 W |
| Sleep mode |
Yes |
| Power consumption (off) |
0.1 W |
| Power consumption (standby) |
7.7 W |
| Power supply type |
AC |
| Power consumption (typical) |
34 W |
| Weight & dimensions |
|---|
| Weight |
3.37 kg |
| Height |
236 mm |
| Depth |
247 mm |
| Width |
300 mm |
| Packaging data |
|---|
| Package weight |
4.2 kg |
| Package height |
334 mm |
| Package depth |
288 mm |
| Package width |
393 mm |
| Quantity per pack |
1 pc(s) |
| System requirements |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
10 - 90% |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
5 - 35 °C |
| Other features |
|---|
| Certification |
GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0 |
| Cable lock slot |
Yes |
| Logistics data |
|---|
| Harmonized System (HS) code |
84716070 |
