Print quotations, invoices, and other reports whilst on the move and streamline the work of field sales, field service, logistics, delivery and the emergency service sectors. The PJ-862 supports both charging and data transfer via USB-C, as well as Bluetooth connectivity to provide a mobile A4 print solution which is compact enough to fit easily into a briefcase or computer bag, but that can also be permanently installed in vehicles. Thermal print technology at 203x200dpi produces crisp text at a print speed of up to 13.5 pages per minute. Compatible with a wide range of mobile and desktop operating systems, the PJ-862 can easily be integrated into your own apps and software using the various SDK's (Software Development Kits) available. Also supports a variety of printer command languages, including ZPL2 emulation.
| Printing |
| Printing characters |
2D barcode, Barcode, Text |
| Print speed |
76.2 mm/sec |
| Maximum resolution |
203 x 200 DPI |
| Type |
Mobile printer |
| Print technology |
Direct thermal |
| Paper handling |
| Maximum printing width |
20.3 cm |
| Printing media thickness |
160 µm |
| Ports & interfaces |
| Bluetooth profiles |
GATT, HCRP, OPP, SPP |
| Bluetooth version |
5.2 |
| Bluetooth Low Energy (BLE) |
Yes |
| Bluetooth |
Yes |
| USB connector |
USB Type-C |
| USB port |
Yes |
| Connectivity technology |
Wired & Wireless |
| Features |
| Country of origin |
China |
| Flash memory |
64 MB |
| Internal memory |
256 MB |
| Design |
| Built-in display |
No |
| Product colour |
Black |
| Power |
| Power source type |
USB |
| System requirements |
| Linux operating systems supported |
Yes |
| Mobile operating systems supported |
Android |
| Mac operating systems supported |
Yes |
| Mac compatibility |
Yes |
| Windows operating systems supported |
Yes |
| Weight & dimensions |
| Weight |
582 g |
| Height |
75 mm |
| Depth |
310 mm |
| Width |
170 mm |
| Packaging data |
| Package weight |
904 g |
| Logistics data |
| Layers per pallet |
8 pc(s) |
| Master (outer) cases per pallet |
48 pc(s) |
| Pallet gross weight |
235.9 kg |
| Pallet gross height |
16.3 cm |
| Products per pallet |
240 pc(s) |
| Technical details |
| Master (outer) cases per pallet layer |
6 pc(s) |
| Pallet type |
800 x 1200 mm |
