What is AOC?
AOC is short for Active Optical Cable which is the latest in cabling technology. AOC removes the copper conductors and replaces them with fibre optical cores and a small transmitter and receiver in the connectors. Copper cores still remain to carry power along the cable.
Why Professionals Are Choosing AOC?
- The use of fibre optical cores allows the cable to be thinner and lighter
- The barriers of cable length is no longer a problem
- By using fibre optical cores, EMC interference from power cables and lighting is no longer an issue. The cables also produce much less EMC themselves
- No signal loss over long distances
- No extenders, boosters or runs of CAT5e needed. These simply connect to your host and device like a standard cable
- Our AOC comes in frustration free packaging
| Features |
|---|
| Product colour |
Black |
| Maximum data transfer rate |
10 Gbit/s |
| Connector contacts plating |
Gold |
| Connector 2 form factor |
Straight |
| Connector 1 form factor |
Straight |
| Connector 2 gender |
Male |
| Connector 1 gender |
Male |
| Connector 2 |
USB C |
| Connector 1 |
USB C |
| USB version |
USB 3.2 Gen 1 (3.1 Gen 1) |
| Power |
|---|
| Input voltage |
5 V |
| Input current (max) |
0.9 A |
| Weight & dimensions |
|---|
| Cable diameter |
4.5 mm |
| Cable length |
10 m |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
