Outstandingly portable and ADF-equipped
The P-208ll now comes equipped with ADF that can hold up to 10 documents. With its compact design, this lightweight scanner — weighing just 600g and measuring 312.5 x 55.5 x 40mm — is small enough to fit neatly into a bag for quick and easy use wherever you go.
Plug & Scan
There is no need to install any driver software or scanning application on your PC as the pre-installed scanning utility, CaptureOnTouch Lite, provides plug-and-scan capabilities. Simply opening the feed tray turns the scanner on and makes it ready to scan.
USB Powering
For enhanced portability, it now comes loaded with a USB bus power drive that makes scanning possible without an AC/DC adaptor. You can scan wherever and whenever the need arises using a single USB cable that packs away neatly when the job is done.
Full auto mode
This mode allows you to scan documents that contain pages of varying type under conditions that best suit each type. The mode also includes the Skip Blank Page function for efficient scanning of only the necessary pages.
Picture mode
Use the picture scanning mode to reproduce gradation in colour more accurately in scanned image.
| Scanning |
|---|
| Black/white scanning colour modes |
Grayscale |
| Duplex ADF scan speed (b/w, A4) |
16 ipm |
| Duplex ADF scan speed (colour, A4) |
12 ipm |
| ADF scan speed (colour, A4) |
6 ppm |
| ADF scan speed (b/w, A4) |
8 ppm |
| Greyscale levels |
256 |
| Film scanning |
No |
| Input colour depth |
24 bit |
| Duplex scanning |
Yes |
| Colour scanning |
Yes |
| Optical scanning resolution |
600 x 600 DPI |
| Maximum scan size |
216 x 356 mm |
| Design |
|---|
| Product colour |
Black |
| Built-in display |
No |
| Scanner type |
Sheet-fed scanner |
| Performance |
|---|
| Scan drivers |
ISIS, TWAIN |
| Light source |
LED |
| Sensor type |
CIS |
| Input capacity |
|---|
| Standard input capacity |
1 sheets |
| Paper handling |
|---|
| Maximum scan area (ADF) |
216 x 356 mm |
| Minimum scan area (ADF) |
50.8 x 70 mm |
| Auto Document Feeder (ADF) media weight |
52 - 380 g/m² |
| Letter |
Yes |
| ISO A-series sizes (A0...A9) |
A4 |
| Scanning media types supported |
Business Card, Card stock, Plain paper, Post Card(JPN) |
| Maximum ISO A-series paper size |
A4 |
| Ports & interfaces |
|---|
| Standard interfaces |
USB 2.0 |
| USB version |
2.0 |
| USB port |
Yes |
| Power |
|---|
| Current |
0.5 A |
| Power consumption (off) |
0.1 W |
| Power consumption (standby) |
1.5 W |
| Power supply type |
USB |
| Power consumption (typical) |
2.5 W |
| Weight & dimensions |
|---|
| Weight |
600 g |
| Height |
40 mm |
| Depth |
89.5 mm |
| Width |
312.5 mm |
| General |
|---|
| Product family |
imageFORMULA |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR |
| System requirements |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
25 - 80% |
| Operating temperature (T-T) |
10 - 32.5 °C |
| Other features |
|---|
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Harmonized System (HS) code |
84716070 |
