Ideal use cases
Performance-critical wireless LANs
High-density environments
Challenging RF scenarios
Focused coverage and flexible deployments
Hardware features
4 radios: 2.4 GHz, 5 GHz, dual-band WIDS/WIPS, and Bluetooth Low Energy (BLE)
4-stream UL/DL MU-MIMO 802.11ax, up to 3.55 Gbps dual aggregate frame rate
6 × external RP-TNC antenna connectors
1 × 2.5 Gbps Multigigabit Ethernet port
PoE: 802.3at
AC adapter available
Cloud management
Network-wide visibility and control
Integrated analytics, reporting, and anomaly detection across networks
Self-provisioning for rapid deployment
Seamless firmware updates
Redundancy and security built into cloud architecture
Analytics
Location analytics: measure visitor capture rate, visit length, and repeat visit rate over time and across sites
Real-time and historical AP event data across radios
Global L7 traffic analytics reporting per device, network, and application
Enterprise security
802.1X and native Active Directory integration
Air Marshal:real-time WIPS with forensics
Stateful Layer 3-7 firewall
Identity-based group policies
Built-in antivirus scan (NAC)
Built-in Umbrella DNS Security*
Adaptive Policy automated segmentation**
Guest access
1-click secure guest access
Guest isolation firewall
Customizable splash pages
Integrated Facebook and Google login
Cisco ISE integration for guest access and BYOD posturing
RF optimization
Dual-concurrent radios with MU-MIMO support
Radios optimized for rate-vs-range performance
Third radio dedicated to security and RF management
Built-in real-time RF spectrum view
Cloud-based automatic RF optimization
Layer 7 traffic shaping
Classifies hundreds of applications
Create per-application bandwidth limits
Prioritize productivity apps
Restrict or block recreational traffic
Device management
Create device-specific firewall rules
Monitor and track device inventory
Deploy applications and enforce security settings
Enterprise Mobility Management (EMM) and Mobility Device Management (MDM) integration
| Features |
|---|
| Quality of Service (QoS) support |
Yes |
| Maximal-Ratio Combining (MRC) |
Yes |
| Modulation |
1024-QAM |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| 5 GHz |
Yes |
| 2.4 GHz |
Yes |
| Security |
|---|
| Security algorithms |
EAP-TLS, EAP-TTLS, WPA, WPA2-Enterprise, WPA2-PSK |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
|---|
| Power consumption (max) |
18 W |
| AC input voltage |
12 V |
| Power over Ethernet (PoE) |
Yes |
| Design |
|---|
| Product colour |
White |
| Placement |
Table, Wall |
| Antenna |
|---|
| Antenna type |
External |
| General |
|---|
| Product family |
Meraki |
| Weight & dimensions |
|---|
| Weight |
850 g |
| Height |
34.9 mm |
| Depth |
156.2 mm |
| Width |
307.2 mm |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
