Meraki cloud-managed switches feature ease of multi-site management through a dashboard used to manage the entire Meraki portfolio. Meraki switches feature excellent tools for reducing TCO: zero-touch configuration and remote troubleshooting.
- General purpose switch for branch deployments
- Physical and virtual stacking
- Redundant power
| Management features |
|---|
| System event log |
Yes |
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2 |
| Switch type |
Managed |
| Ports & interfaces |
|---|
| SFP+ module slots quantity |
4 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Network |
|---|
| Number of VLANs |
4095 |
| VLAN support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Broadcast storm control |
Yes |
| Spanning tree protocol |
Yes |
| Port mirroring |
Yes |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1w |
| Data transmission |
|---|
| Number of queues |
8 |
| Switching capacity |
128 Gbit/s |
| MAC address table |
16000 entries |
| Security |
|---|
| IGMP snooping |
Yes |
| Access Control List (ACL) |
Yes |
| DHCP features |
DHCP server, DHCP client |
| Multicast features |
|---|
| Multicast support |
Yes |
| Design |
|---|
| Product colour |
Grey |
| Form factor |
1U |
| Stackable |
Yes |
| Rack mounting |
Yes |
| Performance |
|---|
| Mean time between failures (MTBF) |
391648 h |
| Power |
|---|
| Power consumption (max) |
448 W |
| Power consumption (typical) |
21 W |
| AC input frequency |
47/63 Hz |
| AC input voltage |
100 - 240 V |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
3.71 kg |
| Height |
43.8 mm |
| Depth |
250 mm |
| Width |
484.6 mm |
| General |
|---|
| Product family |
Meraki |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
