Security that revolves around you
The industry's most secure thin client with Dell ThinOS optimised for Dell cloud client software solutions, now designed by OptiPlex.
| Processor |
| Processor cache |
4 MB |
| Processor boost frequency |
2.9 GHz |
| Processor cores |
4 |
| Processor threads |
4 |
| Processor model |
N5105 |
| Processor family |
Intel® Celeron® N |
| Processor manufacturer |
Intel |
| Processor frequency |
2 GHz |
| Memory |
| Maximum internal memory |
16 GB |
| Memory layout (slots x size) |
1 x 8 GB |
| Memory slots |
2x SO-DIMM |
| Memory clock speed |
2933 MHz |
| Internal memory type |
DDR4-SDRAM |
| Internal memory |
8 GB |
| Storage |
| Storage media |
eMMC |
| Total storage capacity |
64 GB |
| Graphics |
| On-board graphics card model |
Intel® UHD Graphics |
| On-board GPU manufacturer |
Intel |
| On-board graphics card |
Yes |
| Network |
| WLAN controller model |
Intel Wi-Fi 6E AX210 |
| WLAN controller manufacturer |
Intel |
| Bluetooth |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Wi-Fi |
Yes |
| Ports & interfaces |
| DisplayPorts quantity |
2 |
| DC-in jack |
Yes |
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 2.0 ports quantity |
3 |
| Ethernet LAN (RJ-45) ports |
1 |
| Design |
| Cable lock slot type |
Kensington |
| VESA mounting |
Yes |
| Product colour |
Black |
| Display |
| Display included |
No |
| Software |
| Trusted Platform Module (TPM) |
Yes |
| Operating system installed |
Wyse ThinOS |
| Power |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power supply |
65 W |
| Operational conditions |
| Operating altitude |
-15.2 - 3048 m |
| Non-operating altitude |
-15.2 - 10668 m |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating temperature (T-T) |
10 - 40 °C |
| Weight & dimensions |
| Weight |
1.1 kg |
| Height |
182 mm |
| Depth |
178 mm |
| Width |
36 mm |
| General |
| Product family |
OptiPlex |
| Product series |
3000 |
| Carbon footprint |
| Total carbon emissions, standard deviation (kg of CO2e) |
50.7 |
| Carbon emissions, manufacturing (kg of CO2e) |
155.5 |
| Carbon emissions, logistics (kg of CO2e) |
6.31 |
| Carbon emissions, energy usage (kg of CO2e) |
44.9 |
| Carbon emissions, end-of-life (kg of CO2e) |
1.2 |
| PAIA version |
1.3.1, 2022 |
| Total carbon footprint (kg of CO2e) |
208 |
| Packaging content |
| Cables included |
AC |
| Mouse included on selected markets |
MS116 |
