Made for team collaboration, this monitor provides up to 90W power delivery via USB-C and flexibility to include an OptiPlex Micro based on your needs.
| Display |
|---|
| Colour gamut |
72% |
| Surface hardness |
3H |
| Supported graphics resolutions |
640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1152, 2560 x 1440, 3840 x 2160 |
| Supported video modes |
480p, 576p, 720p, 1080i, 1080p, 2160p |
| Colour depth |
8 bit |
| Horizontal scan range |
30 - 140 kHz |
| Vertical scan range |
24 - 75 Hz |
| Haze rate |
25% |
| Display diagonal (metric) |
138.787 cm |
| Active display area (W x H) |
1209.6 x 680.4 mm |
| Pixel pitch |
0.315 x 0.315 mm |
| Display number of colours |
1.07 billion colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Contrast ratio (typical) |
1200:1 |
| Response time |
8 ms |
| Native aspect ratio |
16:9 |
| Touchscreen |
No |
| HD type |
4K Ultra HD |
| Display brightness |
400 cd/m² |
| Display resolution |
3840 x 2160 pixels |
| LED backlighting type |
Edge-LED |
| LED backlight |
Yes |
| Panel type |
IPS |
| Display technology |
LCD |
| Display diagonal |
138.8 cm (54.6") |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| RS-232C |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Power Delivery up to |
90 W |
| USB Power Delivery (USB PD) |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 2.0 Type-B ports quantity |
1 |
| USB connector type |
USB Type-A, USB Type-B, USB Type-C |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| USB port |
Yes |
| DisplayPort version |
1.4 |
| DisplayPorts quantity |
2 |
| DVI port |
No |
| HDMI version |
2.0 |
| HDMI ports quantity |
2 |
| Audio |
|---|
| RMS rated power |
20 W |
| Number of built-in speakers |
2 |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Anti-glare screen |
Yes |
| Bezel width (top) |
1.89 cm |
| Bezel width (side) |
1.89 cm |
| Bezel width (bottom) |
2.85 cm |
| Panel mounting interface |
300 x 400 mm |
| VESA mounting |
Yes |
| Placement supported |
Indoor |
| Product colour |
Black |
| Product design |
Digital signage flat panel |
| Performance |
|---|
| Purpose |
Commercial |
| Power |
|---|
| AC input frequency |
50/60 Hz |
| AC input voltage |
100-240 V |
| Energy consumption (SDR) per 1000 hours |
77 kWh |
| Energy efficiency class (SDR) |
E |
| Power consumption (max) |
300 W |
| Power consumption (off) |
0.3 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
77.1 W |
| Weight & dimensions |
|---|
| Weight |
22.4 kg |
| Height |
727.8 mm |
| Depth |
79.8 mm |
| Width |
1247.4 mm |
| Packaging data |
|---|
| Package weight |
33.8 kg |
| Packaging content |
|---|
| Cables included |
AC, DisplayPort, HDMI, USB, USB Type-C |
| Remote control included |
Yes |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
5 - 90% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Operating temperature (T-T) |
0 - 40 °C |
| Carbon footprint |
|---|
| Total carbon footprint (kg of CO2e) |
927 |
| Carbon emissions, manufacturing (kg of CO2e) |
377.289 |
| Carbon emissions, logistics (kg of CO2e) |
63.036 |
| Carbon emissions, energy usage (kg of CO2e) |
373.581 |
| Carbon emissions, end-of-life (kg of CO2e) |
112.167 |
| PAIA version |
GaBi version 1, 2024 |
| Technical details |
|---|
| Sustainability certificates |
ENERGY STAR, TCO |
| Doesn't contain |
Arsenic, Mercury, PVC/BFR |
| Compliance certificates |
RoHS |
| Other features |
|---|
| Quick start guide |
Yes |
| Remote control battery |
AAA x 2 |
