Dell’s most powerful 17" workstation
Our ultra scalable 17.3" mobile workstations feature stunning screen scape and customisable performance with Dell Optimiser for Precision.
| Design |
|---|
| Intel® vPro™ Platform Eligibility |
Yes |
| Market positioning |
Business |
| Form factor |
Clamshell |
| Product colour |
Grey |
| Product type |
Mobile workstation |
| Display |
|---|
| Contrast ratio (typical) |
1000:1 |
| Maximum refresh rate |
60 Hz |
| RGB colour space |
DCI-P3 |
| Colour gamut |
99% |
| Pixel density |
127 ppi |
| Display brightness |
500 cd/m² |
| Anti-glare screen |
Yes |
| LED backlight |
Yes |
| Native aspect ratio |
16:9 |
| Panel type |
WVA |
| HD type |
Full HD |
| Touchscreen |
No |
| Display resolution |
1920 x 1080 pixels |
| Display diagonal |
43.9 cm (17.3") |
| Processor |
|---|
| Configurable TDP-down |
45 W |
| Bus type |
DMI4 |
| Processor cache type |
Smart Cache |
| Processor cache |
30 MB |
| Efficient-core Max Turbo Frequency |
3.8 GHz |
| Performance-core Max Turbo Frequency |
5.3 GHz |
| Processor model |
i7-13850HX |
| Processor generation |
13th gen Intel® Core™ i7 |
| Processor family |
Intel® Core™ i7 |
| Processor manufacturer |
Intel |
| Memory |
|---|
| Non-ECC |
Yes |
| Maximum internal memory |
128 GB |
| Memory layout (slots x size) |
1 x 32 GB |
| Memory clock speed |
5600 MHz |
| Memory form factor |
CAMM module |
| Internal memory type |
DDR5-SDRAM |
| Internal memory |
32 GB |
| Storage |
|---|
| Compatible memory cards |
SD, SDHC, SDXC |
| Card reader integrated |
Yes |
| Optical drive type |
No |
| SSD form factor |
M.2 |
| SSD interface |
PCI Express |
| NVMe |
Yes |
| SSD capacity |
1 TB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
1 TB |
| Storage media |
SSD |
| Total storage capacity |
1 TB |
| Graphics |
|---|
| On-board graphics card model |
Intel® UHD Graphics |
| On-board GPU manufacturer |
Intel |
| Discrete graphics memory type |
GDDR6 |
| Discrete graphics card memory |
12 GB |
| Discrete graphics card model |
NVIDIA RTX 3500 Ada |
| Discrete graphics card |
Yes |
| On-board graphics card |
Yes |
| Audio |
|---|
| Built-in microphone |
Yes |
| Number of microphones |
2 |
| Speaker power |
2 W |
| Number of built-in speakers |
2 |
| Audio chip |
Realtek ALC3281 |
| Camera |
|---|
| Infrared (IR) camera |
Yes |
| Video capturing speed |
30 fps |
| Front camera resolution |
1920 x 1080 pixels |
| Front camera HD type |
Full HD |
| Front camera resolution (numeric) |
0.92 MP |
| Front camera |
Yes |
| Network |
|---|
| Bluetooth |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| WLAN controller manufacturer |
Intel |
| Wi-Fi data rate (max) |
2400 Mbit/s |
| Antenna type |
2x2 |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Mobile network connection |
No |
| Ports & interfaces |
|---|
| Number of USB ports with PowerShare support |
1 |
| PowerShare |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Power adapter barrel connector |
7.4 mm |
| Combo headphone/mic port |
Yes |
| Intel® Thunderbolt 4 |
Yes |
| Thunderbolt 4 ports quantity |
2 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Performance |
|---|
| Accelerometer |
Yes |
| Hall sensor |
Yes |
| Ambient light sensor |
Yes |
| Keyboard |
|---|
| Keyboard number of keys |
100 |
| Numeric keypad |
Yes |
| Keyboard backlit |
Yes |
| Keyboard language |
UK English |
| Pointing device |
Touchpad |
| Software |
|---|
| Operating system architecture |
64-bit |
| Processor special features |
|---|
| CPU configuration (max) |
1 |
| Battery |
|---|
| Battery charge indicator |
Yes |
| Battery weight |
410 g |
| Fast charging |
Yes |
| Battery recharge time |
3 h |
| Battery voltage |
11.55 V |
| Battery capacity |
93 Wh |
| Number of battery cells |
6 |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Power |
|---|
| DC-in jack |
Yes |
| AC adapter output current |
12.3 A |
| AC adapter input voltage |
100 - 240 V |
| AC adapter frequency |
50 - 60 Hz |
| AC adapter power |
240 W |
| Security |
|---|
| Password protection |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Smart card reader |
Yes |
| Cable lock slot type |
Wedge |
| Cable lock slot |
Yes |
| Operational conditions |
|---|
| Non-operating vibration |
1.3 G |
| Operating vibration |
0.66 G |
| Non-operating shock |
160 G |
| Operating shock |
110 G |
| Non-operating altitude |
-15.2 - 10668 m |
| Operating altitude |
-15.2 - 3048 m |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating temperature (T-T) |
0 - 35 °C |
| Weight & dimensions |
|---|
| Height (rear) |
2.67 cm |
| Height (front) |
2.6 cm |
| Depth |
265 mm |
| Width |
398 mm |
| Weight |
3.02 kg |
| General |
|---|
| Product family |
Precision |
| Product series |
7000 |
| Carbon footprint |
|---|
| Total carbon footprint (kg of CO2e) |
510 |
| Total carbon emissions, standard deviation (kg of CO2e) |
104 |
| Carbon emissions, manufacturing (kg of CO2e) |
404.12 |
| Carbon emissions, logistics (kg of CO2e) |
18.547 |
| Carbon emissions, energy usage (kg of CO2e) |
84.8 |
| Carbon emissions, end-of-life (kg of CO2e) |
2.343 |
| Total carbon emissions, w/o use phase (kg of CO2e) |
425.2 |
| PAIA version |
1.3.2, 2022 |
| Packaging content |
|---|
| Cables included |
AC |
