The Eaton 5S UPS provides cost-effective line-interactive backup power and voltage regulation for small and medium businesses with workstations, desktop PCs, telephone equipment and POS applications. With its compact form factor, the 5S UPS can be utilized as a standalone tower or under a computer monitor.
| Features |
|---|
| Power protection features |
Overdischarge |
| Surge protection features |
Network |
| Surge protection |
Yes |
| Noise level |
25 dB |
| Output power factor |
0.6 |
| Power factor |
0.6 |
| Efficiency |
97% |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Automatic Voltage Regulation (AVR) |
Yes |
| Output frequency |
50/60 Hz |
| Output operation voltage (max) |
276 V |
| Output operation voltage (min) |
184 V |
| Input frequency |
46/70 Hz |
| Input operation voltage (max) |
275 V |
| Input operation voltage (min) |
175 V |
| Output power |
420 W |
| Output power capacity |
0.7 kVA |
| UPS topology |
Line-Interactive |
| Ports & interfaces |
|---|
| USB port |
Yes |
| Power plug |
C14 coupler |
| AC outlet types |
C13 coupler |
| Battery |
|---|
| Automatic battery test |
Yes |
| Battery capacity |
9 Ah |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Design |
|---|
| LED indicators |
Yes |
| Product colour |
Black |
| Form factor |
Tower |
| Operational conditions |
|---|
| Operating altitude |
0 - 2000 m |
| Operating relative humidity (H-H) |
0 - 85% |
| Operating temperature (T-T) |
0 - 35 °C |
| Packaging content |
|---|
| Cables included |
Input power cable, USB cable |
| Certificates |
|---|
| Certification |
IEC/EN 62040-1IEC/EN 62040-2EAC |
| Compliance certificates |
CE |
