The Elo Touch Solutions 1523L 15-inch touchmonitor is well-suited to meet the durability and aesthetic requirements for a variety of high traffic retail and hospitality interactive solutions. Retail peripheral accessories include an encryptable MSR, NFC/RFID for contactless payments, webcam, and rear-facing display bracket.
The edge to edge flat glass style of the 1523L brings a sleek, modern feel to any application. It is available in two touchscreen technologies, IntelliTouch Zero-Bezel surface acoustic wave, and IntelliTouch Pro projected capacitive with anti-glare surface coating, supporting 10-touch interaction right out of the box.
Both touch technologies provide a stable "drift-free" operation with outstanding image clarity, resolution and light transmission - for an accurate touch response and vivid images.
| Display |
|---|
| Contrast ratio (typical) |
700:1 |
| Response time |
16 ms |
| Viewing angle, horizontal |
160° |
| Viewing angle, vertical |
140° |
| Native aspect ratio |
4:3 |
| LED backlight |
Yes |
| Touchscreen |
Yes |
| Display brightness |
270 cd/m² |
| Display resolution |
1024 x 768 pixels |
| Display diagonal |
38.1 cm (15") |
| Features |
|---|
| Mean time between failures (MTBF) |
50000 h |
| Product colour |
Black |
| Packaging data |
|---|
| Package width |
447 mm |
| Package depth |
207 mm |
| Package height |
380 mm |
| Package weight |
7 kg |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
10 - 95% |
