Faster, better inkjet technology
Inkjet technology means that not only are printouts more detailed (600dpi compared to 180dpi for existing models), they’re around twice as fast too, with a print speed of 100mm/s (23.2lps) compared to 43mm/s (13.5lps) for previous models.
Low TCO
Epson has managed to incorporate inkjet technology into this new model while retaining a similar low total cost of ownership to previous dot matrix printers.
Simple maintenance
The ink cartridges have an easy-install design ideal for busy retail counters, as well as drop-in paper roll for quick loading, and the ink formulation used offers better water and light resistance than dot matrix, so receipts and documents will last longer.
Backwards compatible
To make upgrading from existing models incredibly easy, the TM-J7700 is fully backwards-compatible with the TM-J7500 and has exactly the same footprint, so it can simply be swapped in. However, to integrate smoothly with the latest ePOS systems, the model offers both USB and Ethernet connection options.
| Printing |
|---|
| Alphanumeric memory |
95 |
| Character sets |
ANK |
| Printing characters |
Text, Graphic, Barcode |
| Print speed (slip) |
85 mm/sec |
| Print speed (receipt) |
98 mm/sec |
| Print speed (graphic) |
98 mm/sec |
| Print speed |
98 mm/sec |
| Colour |
No |
| Type |
POS printer |
| Print technology |
Inkjet |
| Paper handling |
|---|
| Maximum paper size (slip) |
230 x 297 mm |
| Media thickness |
0.06 - 0.09 mm |
| Supported paper width |
58 - 83 mm |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| USB connector |
USB Type-B |
| USB 2.0 ports quantity |
1 |
| USB port |
Yes |
| Connectivity technology |
Wired |
| Network |
|---|
| Wi-Fi |
No |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Ethernet LAN |
Yes |
| Features |
|---|
| Certification |
CE, EN55024, EN55032 Class A, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-11 |
| Safety |
TÜV, TÜV (EN60950-1) |
| Printer receipt unit life |
3700000000 lines |
| Printer slip unit life |
5000000 lines |
| Country of origin |
China |
| Autocutter durability |
1.5 million cuts |
| Half-cutter |
No |
| Mean time between failures (MTBF) |
180000 h |
| Sound pressure level (printing) |
55 dB |
| Design |
|---|
| Product colour |
Black |
| Power |
|---|
| Power consumption (standby) |
70000 mA |
| AC input voltage |
24 V |
| Operational conditions |
|---|
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-20 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
20 - 85% |
| Weight & dimensions |
|---|
| Weight |
5.8 kg |
| Height |
188 mm |
| Depth |
260 mm |
| Width |
251 mm |
| Packaging data |
|---|
| Package weight |
7.88 kg |
| Package height |
310 mm |
| Package depth |
390 mm |
| Package width |
350 mm |
| Quantity per pack |
1 pc(s) |
| Cables included |
AC |
| Logistics data |
|---|
| Pallet height (UK) |
111 cm |
| Pallet length (UK) |
120 cm |
| Pallet width (UK) |
100 cm |
| Products per pallet layer (UK) |
6 pc(s) |
| Products per pallet (UK) |
36 pc(s) |
| Pallet gross weight |
0 g |
| Pallet gross height |
111 cm |
| Pallet gross length |
120 cm |
| Pallet gross width |
80 cm |
| Products per pallet layer |
6 pc(s) |
| Products per pallet |
36 pc(s) |
| Harmonized System (HS) code |
84433210 |
| Pallet weight (UK) |
0 g |
| Technical details |
|---|
| Font styles |
ANK |
| Other features |
|---|
| Mean cycles between failures (MCBF) |
5000000 |
| Paper dimensions |
58 mm - 83 mm |
