The GXP1630 comes equipped with a suite of VoIP features that are deployed in a clear and easy-to-use fashion. Focused primarily for low to medium call volumes and efficient call handling, its 3 line/SIP account design and 8 dual-colored BLF/speed dial keys gives this versatility. The GXP1630 also supports the best possible connection speeds and call quality with its dual Gigabit ports and HD audio on both speakerphone and handset. With other features such as its integrated PoE, 3 XML programmable soft keys and 4-way conferencing support, the GXP1630 is a high-quality and versatile Basic IP phone.
As all Grandstream IP phones do, the GXP1630 features state-of-the-art security encryption technology (SRTP and TLS). The GXP1630 supports a variety of automated provisioning options, including zero-configuration with Grandstream’s UCM series IP PBXs, encrypted XML files and TR-069, to make mass deployment extremely easy.
| Design |
|---|
| Mounting |
Desk/Wall |
| Product colour |
Black, Grey |
| Handset type |
Wired handset |
| Product type |
IP Phone |
| Performance |
|---|
| Operating system installed |
Linux |
| Phone features |
|---|
| Caller ID |
Yes |
| Phonebook capacity |
1000 entries |
| Number of VoIP accounts |
3 |
| Call pick up |
Yes |
| Speed dialling |
Yes |
| Call forwarding |
Yes |
| Conference call |
Yes |
| Redialing |
Yes |
| Call transfer |
Yes |
| Call park |
Yes |
| Call history |
Yes |
| Call log entries |
200 |
| Answering machine |
Yes |
| Lines quantity |
3 lines |
| Management features |
|---|
| Firmware upgradeable |
Yes |
| Number of programmable keys |
3 |
| Display |
|---|
| Touchscreen |
No |
| Display resolution |
132 x 64 pixels |
| Display diagonal |
7.57 cm (2.98") |
| Display |
LCD |
| Audio |
|---|
| Voice codecs |
AJB, CNG, G.711Mu, G.711a, G.722, G.723, G.726-32, G.729, PLC, VAD, iLBC |
| Speakerphone |
Yes |
| Network |
|---|
| Supported network protocols |
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP, CDP/SNMP/RTCP-XR |
| Quality of Service (QoS) support |
Yes |
| Security algorithms |
256-bit AES, HTTPS, MD5, SRTP, TLS |
| Networking standards |
IEEE 802.3af, IEEE 802.3az |
| Bluetooth |
No |
| Wi-Fi |
No |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
2 |
| RJ-9 ports quantity |
1 |
| Certificates |
|---|
| Certification |
FCC: Part 15 (CFR 47) Class B CE : EN55022 Class B, EN55024 Class B; EN61000-3-2, EN61000-3-3, EN60950-1 RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 60950.1 |
| Power |
|---|
| AC adapter output current |
0.6 A |
| AC adapter output voltage |
5 V |
| Input frequency |
50/60 Hz |
| AC adapter input voltage |
100 - 240 V |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-10 - 60 °C |
| Weight & dimensions |
|---|
| Package weight |
1.2 kg |
| Weight |
800 g |
| Height |
76.2 mm |
| Depth |
208.5 mm |
| Width |
222.5 mm |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Quick start guide |
Yes |
| Number of handles included |
1 pc(s) |
| Cables included |
LAN (RJ-45) |
| Logistics data |
|---|
| Harmonized System (HS) code |
85171800 |
