Hanwha HCV-7070RA security camera Dome CCTV security camera Outdoor 2560 x 1440 pixels Ceiling/wall
Regular price
£166.07
- QHD (2560 x 1440, 30fps) resolution
- 0.16 Lux@F1.6 (Color), 0 Lux (B/W : IR LED on)
- 3.2 ~ 10mm (3.1x) varifocal lens
- Day & Night (ICR), DWDR, Motion detection
- Transmission distance Max. 500m
- Easy installation (Plug & play), Dual power
- IP66, IK10 support
| Performance | |
|---|---|
| Alarm input/output | Yes |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Maximum operating distance | 500 m |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Type | CCTV security camera |
| Design | |
|---|---|
| IK code | IK10 |
| International Protection (IP) code | IP66 |
| Housing material | Aluminium |
| Product colour | Ivory |
| Mounting type | Ceiling/wall |
| Form factor | Dome |
| Camera | |
|---|---|
| Camera shutter speed | 1/30 - 1/12000, 1/25- 1/12000 s |
| Camera shutter type | Electronic |
| White balance | ATW, AWC, Indoor, Manual, Outdoor |
| Pan range | 0 - 350° |
| Tilt angle range | 0 - 63° |
| Lens viewing angle, diagonal | 112.53° |
| Lens viewing angle, vertical | 50.47° |
| Lens viewing angle, horizontal | 93.48° |
| Angle of rotation | 355° |
| Minimum illumination | 0 lx |
| Camera tilt control | Yes |
| Camera pan control | Yes |
| Image sensor | |
|---|---|
| Number of effective pixels (H x V) | 2688 x 1520 pixels |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Number of sensors | 1 |
| Sensor type | CMOS |
| Lens system | |
|---|---|
| Closest focusing distance | 0.5 m |
| Maximum aperture number | 1.6 |
| Focus | Manual |
| Focal length range | 3.2 - 10 mm |
| Zoom capability | Yes |
| Number of lenses | 1 |
| Night vision | |
|---|---|
| LED type | IR |
| Night vision distance | 30 m |
| Night vision | Yes |
| Video | |
|---|---|
| Highlight Compensation (HLC) | Yes |
| Privacy masking | Yes |
| Back Light Compensation (BLC) | Yes |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Noise reduction | Yes |
| Frame rate | 30 fps |
| Total megapixels | 4 MP |
| Maximum resolution | 2560 x 1440 pixels |
| Network | |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | No |
| Security | |
|---|---|
| Video motion detection | Yes |
| Power | |
|---|---|
| DC output voltage | 12 |
| Power consumption (max) | 5.8 W |
| Power source type | AC, DC |
| Weight & dimensions | |
|---|---|
| Diameter | 13.7 cm |
| Height | 106.1 mm |
| Packaging content | |
|---|---|
| Number of cameras | 1 |
