Weight and size reduced up to 55%, better performance, easier installation
New Q series PTZ reduced the weight by up to 55% for the Dome type (QNP-6230RH) and the size became more compact than conventional PTZ cameras. More compact and lighter design significantly reduce the burden of installation.
Moreover, the lightened head increased the speed of Pan/Tilt.
Precise PTZ control
New Q series PTZ supports delicate and precise PTZ control. Conventional PTZ cameras had challenges in offering precise monitoring of moving objects due to its pre-set centered movement. New Q series PTZ provides stable object monitoring using precise PTZ control when a user wants to track moving objects manually.
Widened Tilt angle
QNP-6320R/6250R offers 110º (-20º ~ 90º) of Tilt angle, enabling effective monitoring of objects positioned above the camera level and objects in sloped environment.
| Performance |
|---|
| Number of languages |
17 |
| Languages support |
Simplified Chinese, Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish |
| Day/night mode |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| PTZ modes |
Preset sequence |
| PTZ control |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Outdoor |
| Type |
IP security camera |
| Design |
|---|
| IK code |
IK10 |
| International Protection (IP) code |
IP66 |
| Housing material |
Aluminium, Polycarbonate (PC) |
| Product colour |
Black, White |
| Mounting type |
Ceiling/wall |
| Form factor |
Dome |
| Camera |
|---|
| White balance |
ATW, AWC, Indoor, Manual, Mercury lamp, Outdoor, Sodium lamp |
| Pan preset speed |
700 °/sec |
| Pan speed |
250 °/sec |
| Pan range |
0 - 360° |
| Tilt speed |
250 °/sec |
| Tilt angle range |
-20 - 90° |
| Minimum illumination |
0.05 lx |
| Image sensor |
|---|
| Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") |
| Sensor type |
CMOS |
| Lens system |
|---|
| Detect distance (wide) |
64.2 m |
| Detect distance (tele) |
1471.3 m |
| Observe distance (wide) |
24.3 m |
| Observe distance (tele) |
588.5 m |
| Recognize distance (wide) |
12.1 m |
| Recognize distance (tele) |
294.3 m |
| Identify distance (wide) |
6.1 m |
| Identify distance (tele) |
147.1 m |
| Minimum aperture number |
1.6 |
| Maximum aperture number |
3.9 |
| Focal length range |
4.44 - 111 mm |
| Zoom capability |
Yes |
| Number of lenses |
1 |
| Video |
|---|
| Highlight Compensation (HLC) |
Yes |
| Privacy masking |
Yes |
| Back Light Compensation (BLC) |
Yes |
| Noise reduction |
Yes |
| Video streaming |
Yes |
| Video intelligence analytic |
Yes |
| Supported graphics resolutions |
320 x 240, 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Total megapixels |
2 MP |
| Maximum resolution |
1920 x 1080 pixels |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
|---|
| IP address filtering |
Yes |
| HTTPS encryption |
Yes |
| Security algorithms |
EAP-LEAP, EAP-TLS, HTTPS, SSL/TLS |
| Alert notification type |
E-mail |
| Power |
|---|
| Power consumption (max) |
25.5 W |
| Power source type |
PoE |
| Weight & dimensions |
|---|
| Diameter |
15.8 cm |
| Height |
293.3 mm |
| Packaging content |
|---|
| Number of cameras |
1 |
