Max. 2megapixel (1920 x 1080) resolution
0.095Lux (Color), 0Lux (B/W, IR LED on)
3.2 ~ 10mm (3.1x) varifocal lens
Max. 30fps@2M all resolutions (H.265/H.264)
H.265, H.264, MJPEG codec supported, Multiple streaming
Motion detection, Tampering, Defocus detection
Hallway view (90˚/270˚), LDC support
Micro SD/SDHC/SDXC memory slot (Max. 128GB)
IR viewable length 30m
IP66, IK10, PoE/12VDC
| Performance |
|---|
| Languages support |
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish |
| Alarm input/output |
Yes |
| Day/night mode |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Outdoor |
| Type |
IP security camera |
| Design |
|---|
| IK code |
IK10 |
| International Protection (IP) code |
IP66 |
| Protection features |
Vandal proof |
| Housing material |
Aluminium |
| Product colour |
White |
| Mounting type |
Ceiling |
| Form factor |
Dome |
| Camera |
|---|
| Adjustment shutter speed |
Manual |
| Camera shutter type |
Electronic |
| White balance |
ATW, AWC, Indoor, Manual, Outdoor |
| Pan range |
0 - 350° |
| Tilt angle range |
0 - 67° |
| Lens viewing angle, diagonal |
136° |
| Lens viewing angle, vertical |
76.5° |
| Lens viewing angle, horizontal |
104.7° |
| Minimum illumination |
0.095 lx |
| Image sensor |
|---|
| Number of effective pixels (H x V) |
1920 x 1080 pixels |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") |
| Sensor type |
CMOS |
| Lens system |
|---|
| Maximum aperture number |
1.6 |
| Focal length range |
3.2 - 10 mm |
| Night vision |
|---|
| LED type |
IR |
| Night vision distance |
30 m |
| Night vision |
Yes |
| Video |
|---|
| Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Flip & mirror |
Yes |
| Privacy masking |
Yes |
| Back Light Compensation (BLC) |
Yes |
| Gain control type |
Manual |
| Noise reduction |
Yes |
| Video streaming |
Yes |
| Supported graphics resolutions |
640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Video compression formats |
H.264, H.265, M-JPEG |
| Total megapixels |
2 MP |
| Maximum resolution |
1920 x 1080 pixels |
| Network |
|---|
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Storage |
|---|
| Card reader integrated |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
|---|
| Video motion detection |
Yes |
| Active tampering alarm |
Yes |
| IP address filtering |
Yes |
| Alert notification type |
E-mail |
| Power |
|---|
| Power consumption (max) |
7.7 W |
| Power source type |
PoE |
| System requirements |
|---|
| Mac operating systems supported |
Yes |
| Windows operating systems supported |
Yes |
| Weight & dimensions |
|---|
| Diameter |
13.7 cm |
| Height |
106.1 mm |
| Packaging content |
|---|
| Number of cameras |
1 |
