False alarm reduction
Q series AI cameras detect and classify people, vehicles in real time, greatly enhancing the accuracy of video analytics. AI algorithms can discern person as distinct objects separate from their surroundings such as waving trees, shadows, or animals. Q series AI cameras are able to help improve operator efficiency even with conventional motion detection.
Various resolution options from 2MP to 8MP
Q series AI cameras offer a variety of cameras with resolutions ranging from 2MP to 8MP, so users can choose the right one for environmental needs.
| Performance |
|---|
| Certification |
EMC:FCC 47 CFR 15 Subpart B Class AICES-3(A)/NMB-3(A)CE/UKCA- EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3VCCI CISPR 32 Class ARCM AS/NZS CISPR 32 Class ASafety:UL 62368-1, CAN/CSA C22.2 NO. 62368-1IEC/EN 62471Environment:IEC/EN 63000IEC/EN 60529 IP66, IEC/EN 62262 IK10 |
| Languages support |
Simplified Chinese, Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Turkish |
| Alarm input/output |
Yes |
| Day/night mode |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| PTZ modes |
Preset point |
| PTZ control |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Indoor & outdoor |
| Type |
IP security camera |
| Design |
|---|
| IK code |
IK10 |
| International Protection (IP) code |
IP66 |
| Housing material |
Aluminium |
| Product colour |
White |
| Mounting type |
Ceiling |
| Form factor |
Dome |
| Camera |
|---|
| Camera shutter speed |
1/5~1/12000 s |
| Camera shutter type |
Electronic |
| White balance |
ATW, AWC, Indoor, Manual, Outdoor |
| Pan range |
0 - 350° |
| Tilt angle range |
-35 - 70° |
| Lens viewing angle, diagonal |
124° |
| Lens viewing angle, vertical |
55° |
| Lens viewing angle, horizontal |
104° |
| Camera tilt control |
Yes |
| Camera pan control |
Yes |
| Image sensor |
|---|
| Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors |
1 |
| Sensor type |
CMOS |
| Lens system |
|---|
| Detect distance (wide) |
60 m |
| Detect distance (tele) |
176.9 m |
| Observe distance (wide) |
24.2 m |
| Observe distance (tele) |
111.7 m |
| Recognize distance (wide) |
12 m |
| Recognize distance (tele) |
55.4 m |
| Identify distance (wide) |
6 m |
| Identify distance (tele) |
27.7 m |
| Minimum aperture number |
1.6 |
| Maximum aperture number |
3.1 |
| Lens diameter (tele) |
1.02 cm |
| Lens diameter (wide) |
3.2 mm |
| Optical zoom |
3.2x |
| Zoom capability |
Yes |
| Number of lenses |
1 |
| Night vision |
|---|
| LED type |
IR |
| Night vision distance |
30 m |
| Night vision |
Yes |
| Video |
|---|
| Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Flip & mirror |
Yes |
| Privacy masking |
Yes |
| Back Light Compensation (BLC) |
Yes |
| Noise reduction technology |
Smart Super Noise Reduction V (SSNR V), WiseNR Ⅱ |
| Noise reduction |
Yes |
| Video streaming |
Yes |
| Frame rate |
30 fps |
| Supported graphics resolutions |
320 x 240, 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 960, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2592 x 1944, 2688 x 1520, 3840 x 2160 |
| Video compression formats |
H.264, H.265, M-JPEG |
| Total megapixels |
8 MP |
| Maximum resolution |
3840 x 2160 pixels |
| Network |
|---|
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
|---|
| Video motion detection |
Yes |
| IP address filtering |
Yes |
| Anti-flicker |
Yes |
| Security algorithms |
EAP-LEAP, EAP-PEAP, EAP-TLS, HTTPS, MSCHAPv2, SRTP |
| Alert notification type |
E-mail |
| Power |
|---|
| Power consumption (max) |
12.95 W |
| Power source type |
PoE |
| Weight & dimensions |
|---|
| Diameter |
14 cm |
| Height |
110.2 mm |
| Packaging content |
|---|
| Number of cameras |
1 |
