Empowered by deep learning algorithms, Hikvision AcuSense technology brings human and vehicle targets classification alarms to front- and back-end devices. The system focuses
on human and vehicle targets, vastly improving alarm efficiency and effectiveness.
| Performance |
|---|
| Certification |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 + A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015)UL (UL 60950-1);CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013);CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013);LOA (IEC/EN 60950-1)CE-ROHS (2011/65/EU); WEEE (2012/19/EU); REACH (Regulation (EC) No 1907/2006) |
| Number of languages |
33 |
| Languages support |
Multi |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Indoor & outdoor |
| Type |
IP security camera |
| Design |
|---|
| International Protection (IP) code |
IP67 |
| Protection features |
Dust resistant, Water resistant |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Form factor |
Bullet |
| Camera |
|---|
| Camera shutter speed |
1/3 - 1/100000 s |
| Pan range |
0 - 360° |
| Tilt angle range |
0 - 90° |
| Lens viewing angle, diagonal |
123° |
| Lens viewing angle, vertical |
55° |
| Lens viewing angle, horizontal |
103° |
| Angle of rotation |
360° |
| Minimum illumination |
0 lx |
| Camera tilt control |
Yes |
| Camera pan control |
Yes |
| Image sensor |
|---|
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 3 mm (1 / 3") |
| Number of sensors |
1 |
| Sensor type |
CMOS |
| Lens system |
|---|
| Detect distance (wide) |
60 m |
| Observe distance (wide) |
23.8 m |
| Recognize distance (wide) |
12 m |
| Identify distance (wide) |
6 m |
| Fixed focal length |
2.8 mm |
| Maximum aperture number |
1.4 |
| Number of lenses |
1 |
| Night vision |
|---|
| Infra-red wavelength |
850 nm |
| LED type |
IR |
| Night vision distance |
60 m |
| Night vision |
Yes |
| Video |
|---|
| Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Highlight Compensation (HLC) |
Yes |
| Region of Interest (ROI) encoding |
Yes |
| Image quality adjustment |
Brightness, Contrast, Saturation, Sharpness |
| Bit rate |
32 Kbps - 8 Mbps |
| Back Light Compensation (BLC) |
Yes |
| Gain control type |
Auto |
| Noise reduction technology |
3D noise reduction |
| Noise reduction |
Yes |
| Video streaming |
Yes |
| Frame rate |
30 fps |
| Supported graphics resolutions |
640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520 |
| Video compression formats |
H.264, H.264+, H.265, H.265+, M-JPEG |
| Total megapixels |
4 MP |
| Maximum resolution |
2688 x 1520 pixels |
| Network |
|---|
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Storage |
|---|
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
|---|
| Video motion detection |
Yes |
| Active tampering alarm |
Yes |
| IP address filtering |
Yes |
| HTTPS encryption |
Yes |
| Anti-flicker |
Yes |
| Audit log |
Yes |
| Heartbeat |
Yes |
| Security algorithms |
TLS |
| Alert notification type |
E-mail |
| Password protection |
Yes |
| Power |
|---|
| DC output voltage |
12 |
| Power consumption (max) |
7.5 W |
| Power source type |
DC, PoE |
| Weight & dimensions |
|---|
| Diameter |
10.5 cm |
| Packaging data |
|---|
| Package weight |
1.58 kg |
| Package height |
155 mm |
| Package depth |
156 mm |
| Package width |
386 mm |
| Packaging content |
|---|
| Number of cameras |
1 |
