Discover Hikvision NVR Family
Hikvision NVR comes in different series, such as Pro, Ultra, DeepinMind, Value, Special series and Pro Series with AcuSense, catering to various application scenarios. Our NVRs are built with high-quality components to ensure the reliability of devices and the whole Network Video Recorder System, while also prioritizing user experience with simplified operation processes. Choose the NVR series below that perfectly fits your needs for a seamless and reliable security solution.
| Performance |
|---|
| Input bandwidth |
320 Mbit/s |
| Output bandwidth |
400 Mbit/s |
| Maximum frame rate |
60 fps |
| Video formats supported |
H.264, H.264+, H.265, H.265+ |
| Audio formats supported |
AAC, G.711 A-law, G.711 μ-law, G.722, G.726, MP2L2 |
| Supported resolutions |
7680 x 4320, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768 |
| Maximum resolution |
7680 x 4320 pixels |
| Video recording modes |
720p, 1080p, 2160p, 4320p |
| Alarm output channels |
9 |
| Alarm input channels |
16 |
| Video input channels |
32 channels |
| Wireless LAN features |
|---|
| Wi-Fi |
No |
| Hard drive |
|---|
| HDD interface |
SATA |
| Number of HDDs supported |
4 |
| Ports & interfaces |
|---|
| Supported network protocols |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Networking standards |
IEEE 802.3af, IEEE 802.3at |
| RS-232 interface |
Yes |
| RS-232 ports |
1 |
| RS-485 ports |
2 |
| eSATA |
Yes |
| eSATA ports quantity |
1 |
| Audio RCA outputs |
1 |
| Audio RCA inputs |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 2.0 ports quantity |
2 |
| HDMI output |
Yes |
| HDMI ports quantity |
2 |
| BNC video output |
Yes |
| Power over Ethernet (PoE) ports quantity |
24 |
| Power over Ethernet (PoE) |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports |
24 |
| Features |
|---|
| Certification |
CE, REACH, WEEE, FCC, CB, RCM, KC, UL |
| LED indicators |
Yes |
| Product colour |
Black, Grey |
| Brand compatibility |
Hikvision Digital Technology |
| Rack capacity |
1.5U |
| Rack mounting |
Yes |
| Power |
|---|
| AC input frequency |
50 - 60 Hz |
| AC input voltage |
100 - 240 V |
| Power consumption (typical) |
15 W |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
-10 - 55 °C |
| Weight & dimensions |
|---|
| Weight |
5 kg |
| Height |
75 mm |
| Depth |
400 mm |
| Width |
445 mm |
| Packaging content |
|---|
| Quick installation guide |
Yes |
