HPE Aruba Networking 630 Series Campus Access Points are designed to take advantage of the 6 GHz band using three radios for comprehensive tri-band coverage. With 6GHz, wireless capacity is more than doubled–allowing enterprises to meet today’s needs and plan for future growth. HPE Aruba Networking Wi-Fi 6E APs allow countries to take advantage of Wi-Fi 6E once it is approved in country via automated notification and easy deployment of 6 GHz regulatory tables.
The HPE Aruba Networking 630 Series delivers a maximum aggregate 3.9 Gbps data rate for higher throughput and faster speeds for fixed low power indoor use. With up to seven 160 MHz channels, the 630 Series maximizes performance for low-latency, bandwidth-hungry applications. The HPE Aruba Networking ultra tri-band filtering eliminates interference between 5 GHz and 6 GHz and prevents gaps in channel coverage. To ensure high availability, the 630 Series includes dual port hitless failover for ethernet and power.
| Features |
| GPS (satellite) |
Yes |
| Modulation |
16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
| MIMO |
Yes |
| Bluetooth version |
5.0 |
| Bluetooth |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frequency band |
2.4/5/6 GHz |
| Ethernet LAN data rates |
100,1000,2500 Mbit/s |
| Maximum data transfer rate |
2400 Mbit/s |
| 5 GHz |
Yes |
| 6 GHz |
Yes |
| 2.4 GHz |
Yes |
| Security |
| Security algorithms |
WPA, WPA2, WPA3 |
| Ports & interfaces |
| USB 2.0 ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| Power |
| Power over Ethernet (PoE) |
Yes |
| Design |
| Product colour |
White |
| Placement |
Ceiling |
| Antenna |
| Antenna gain level (max) |
7 dBi |
| Antenna features |
Integrated antenna |
| Antenna direction type |
Omni-directional |
| Antenna type |
Internal |
| Weight & dimensions |
| Weight |
1.3 kg |
| Height |
51 mm |
| Depth |
220 mm |
| Width |
220 mm |
| Operational conditions |
| Storage relative humidity (H-H) |
10 - 100% |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating temperature (T-T) |
0 - 50 °C |
| Operating relative humidity (H-H) |
5 - 95% |
