Are you searching for an affordable tower server with enterprise-class reliability and performance to meet the requirements of your growing business? The HPE ProLiant ML110 Gen11 server is an enhanced single processor tower with performance, expansion, and security at an affordable price. It supports the 4th and 5th Gen Intel Xeon Scalable processor, HPE DDR5 SmartMemory with a maximum capacity of 1536 GB, 4 x16 PCIe Gen5 slots, 1 x16 OCP3 slot, eight large form factor (LFF) or 16 small form factor (SFF) disk drives. It can easily be converted to a rack using 5.5U of rack space. The HPE ProLiant ML110 Gen11 server also offers optional redundant fan and redundant power supply to satisfy automatic fail-over needs, making this the ideal server for small- to mid-sized businesses, and remote and branch offices.
What is new supporting point:
Supports hot-pluggable, high-availability, RAID1 protected M.2 NVMe boot option.
Support NVIDIA RTX 4000 Ada Graphics Accelerator and L4 24GB PCIe Accelerator
Powered by 4th and 5th Gen Intel Xeon Scalable Processors that support up to 32 cores, 185W TDP.
Increased memory bandwidth to 5600 MT/s[1] , performance and lower power requirements with up to 1.5 TB DDR5 memory capacity with 16 DIMM slots.
Advanced data transfer rates from the PCIe Gen5 serial expansion bus, support up to 4 standard PCIe Gen5 x16 slots and 1 OCP 3.0 x16 slots.
Includes HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly from anywhere.
| Processor |
|---|
| Number of processors installed |
1 |
| Processor cache |
30 MB |
| Processor cores |
12 |
| Processor frequency |
2.4 GHz |
| Processor model |
4510 |
| Processor generation |
Intel Xeon Scalable 4th Gen |
| Processor family |
Intel Xeon Silver |
| Processor manufacturer |
Intel |
| Memory |
|---|
| Maximum internal memory |
1.5 TB |
| Memory slots |
16x DIMM |
| Memory layout (slots x size) |
2 x 32 GB |
| Internal memory type |
DDR5-SDRAM |
| Internal memory |
64 GB |
| Storage |
|---|
| Optical drive type |
No |
| Supported RAID controllers |
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller |
| Number of SSDs supported |
2 |
| SSD interface |
SATA III |
| SSD capacity |
480 GB |
| Number of SSDs installed |
2 |
| Number of HDDs supported |
8 |
| HDD interface |
SATA |
| Number of HDDs installed |
2 |
| Total storage capacity |
960 GB |
| Graphics |
|---|
| Maximum graphics card memory |
16 MB |
| On-board graphics card |
Yes |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
2 |
| Design |
|---|
| Chassis type |
Tower (4.5U) |
| Performance |
|---|
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Software |
|---|
| Operating system installed |
No |
| Power |
|---|
| Number of main power supplies |
2 |
| Power supply |
1000 W |
| Redundant power supply (RPS) support |
Yes |
| General |
|---|
| Product family |
ProLiant |
| Product series |
ML |
