Elevate your visual communication with the LH5560UHS-B2AG and unlock the new possibilities for your business. This 500cd/m² high brightness display is a powerful business tool that takes your marketing and communication efforts to the next level. With its Android 11 OS, iiSignage² (Content Management Software), Signal FailOver, and EShare features, this display offers a straightforward user experience, making content creation, management, and sharing a breeze. This ELED VA display consumes significantly less power compared to DLED IPS while maintaining the same level of brightness. Its versatile orientation, sleek design, and 24/7 reliability ensure it seamlessly integrates into any business environment. Whether it's used in retail, corporate, hospitality, or educational settings, the LH5560UHS-B2AG will undoubtedly captivate your audience and leave a lasting impression.
| Display |
|---|
| Native refresh rate |
60 Hz |
| Surface hardness |
3H |
| Horizontal scan range |
28 - 160 kHz |
| Haze rate |
25% |
| Display diagonal (metric) |
139 cm |
| Active display area (W x H) |
1209.6 x 680.4 mm |
| Pixel pitch |
0.315 x 0.315 mm |
| Display number of colours |
1.07 billion colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Contrast ratio (typical) |
4000:1 |
| Response time |
6.5 ms |
| Native aspect ratio |
16:9 |
| Touchscreen |
No |
| HD type |
4K Ultra HD |
| Display brightness |
500 cd/m² |
| Display resolution |
3840 x 2160 pixels |
| Panel type |
VA |
| Display technology |
LED |
| Display diagonal |
138.7 cm (54.6") |
| Ports & interfaces |
|---|
| RS-232C |
Yes |
| RS-232 interface |
Yes |
| PC Audio in |
Yes |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN |
Yes |
| USB version |
2.0 |
| USB ports quantity |
2 |
| USB port |
Yes |
| DVI port |
No |
| HDMI version |
2.0 |
| HDMI ports quantity |
3 |
| Audio |
|---|
| RMS rated power |
20 W |
| Number of built-in speakers |
2 |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Anti-glare screen |
Yes |
| Bezel colour |
Black |
| Bezel width (top) |
1.33 cm |
| Bezel width (side) |
1.33 cm |
| Bezel width (bottom) |
1.53 cm |
| Panel mounting interface |
300 x 400 mm |
| VESA mounting |
Yes |
| Orientation |
Horizontal/Vertical |
| Placement supported |
Indoor |
| Product colour |
Black |
| Product design |
Digital A-board |
| Performance |
|---|
| Mean time between failures (MTBF) |
50000 h |
| HDCP |
Yes |
| HDCP version |
1.4/2.2 |
| Operating hours (hours/days) |
24/7 |
| Number of OSD languages |
15 |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Polish, Russian, Slovenian |
| Purpose |
Universal |
| Power |
|---|
| Energy efficiency scale |
A to G |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Energy consumption (SDR) per 1000 hours |
54.9 kWh |
| Energy efficiency class (SDR) |
E |
| Power consumption (off) |
0.3 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
55 W |
| Computer system |
|---|
| Operating system installed |
Android 11 |
| Internal storage capacity |
16 GB |
| On-board graphics card model |
ARM Mali-G52 |
| Internal memory |
2 GB |
| Processor cores |
4 |
| Processor architecture |
ARM Cortex-A53 |
| Processor model |
A53 |
| Processor family |
ARM Cortex |
| Processor manufacturer |
ARM |
| Built-in processor |
Yes |
| Computer system |
No |
| Weight & dimensions |
|---|
| Display weight |
17.6 kg |
| Display height |
712.5 mm |
| Display depth |
38.6 mm |
| Display width |
1239.7 mm |
| Packaging data |
|---|
| Package weight |
22.9 kg |
| Package height |
850 mm |
| Package depth |
1390 mm |
| Package width |
1390 mm |
| Packaging content |
|---|
| Cables included |
HDMI, Power, RS-232 |
| Mounting kit |
Yes |
| Batteries included |
Yes |
| Remote control included |
Yes |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Features |
|---|
| Wall mountable |
Yes |
| Technical details |
|---|
| Sustainability certificates |
ErP |
| Compliance certificates |
CB, CE, EAC, REACH, RoHS, TÜV mark, UKCA, WEEE |
| Other features |
|---|
| Quick start guide |
Yes |
| Power supply type |
Internal |
