Enhanced Power Loss Data Protection
Enhanced Power Loss Data Protection prepares the SSD for unexpected system power loss by minimizing data in transition in temporary buffers, and uses on-board power-loss protection capacitance to provide enough energy for the SSD firmware to move data from the transfer buffer and other temporary buffers to the NAND, thus protecting system and user data.
Temperature Monitoring and Logging
Temperature Monitoring and Logging uses an internal temperature sensor to monitor and log airflow and device internal temperature. The logged results can be accessed using the SMART command.
End-to-End Data Protection
End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back.
Intel® Rapid Start Technology
Intel® Rapid Start Technology allows quick system resumes from the hibernate state.
| Features |
|---|
| Temperature monitoring and logging |
Yes |
| SSD ARK ID |
189611 |
| Mean time between failures (MTBF) |
1600000 h |
| Uncorrectable Bit Error Rate (UBER) |
< 1 per 10^15 bits read |
| SSD temperature monitoring |
Yes |
| Enhanced Power Loss Data Protection technology |
Yes |
| End-to-End Data Protection |
Yes |
| Write latency |
18 µs |
| Read latency |
7 µs |
| Component for |
PC/Laptop |
| Memory type |
3D XPoint + QLC 3D NAND |
| NVMe |
Yes |
| Interface |
PCI Express 3.0 |
| SSD form factor |
M.2 |
| SSD capacity |
1 TB |
| Power |
|---|
| Power consumption (idle) |
0.013 W |
| Power consumption (write) |
5.8 W |
| Power consumption (read) |
5.8 W |
| Brand-specific features |
|---|
| Intel® Rapid Start Technology |
Yes |
| Weight & dimensions |
|---|
| Weight |
10 g |
| Height |
22 mm |
| Width |
80 mm |
| Operational conditions |
|---|
| Operating / non-operating shock |
1000 G / 0.5 ms and 1500 G / 0.5 ms |
| Non-operating shock |
1500 G |
| Operating shock |
1000 G |
| Non-operating vibration |
3.13 G |
| Operating vibration |
2.17 G |
| Minimum operating temperature |
0 °C |
| Maximum operating temperature |
70 °C |
| Operating temperature (T-T) |
0 - 70 °C |
| General |
|---|
| Product family |
Optane |
| Other features |
|---|
| Launch date |
04/10/2019 |
| Product brief URL |
https://www.intel.com/content/www/us/en/products/docs/memory-storage/optane-memory/optane-memory-h10-solid-state-storage-brief.html |
| SSD endurance rating |
300 TBW |
| SSD power consumption (idle) |
L1.2 : |
| Sequential reading |
2400 MB/s |
| Sequential writing speed |
1800 MB/s |
| Status |
Launched |
| Random write (8GB span) |
250000 IOPS |
| Random read (8GB span) |
330000 IOPS |
| Logistics data |
|---|
| Harmonized System (HS) code |
84717070 |
