Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.
| Ports & interfaces |
|---|
| Interface |
WLAN / Bluetooth |
| Host interface |
M.2 |
| Connectivity technology |
Wireless |
| Network |
|---|
| Bluetooth version |
5.4 |
| Bluetooth |
Yes |
| Security algorithms |
128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA2, WPA3 |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Wi-Fi band |
Tri-band (2.4 GHz / 5 GHz / 5 GHz) |
| Wi-Fi |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11j, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w |
| Maximum data transfer rate |
5000 Mbit/s |
| Design |
|---|
| Form factor |
M.2 2230 |
| Antenna type |
2x2 |
| Component for |
PC/Laptop |
| Internal |
Yes |
| System requirements |
|---|
| Linux operating systems supported |
Yes |
| Windows operating systems supported |
Windows 10, Windows 11 |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
50 - 90% |
| Operating temperature (T-T) |
0 - 50 °C |
| Weight & dimensions |
|---|
| Weight |
3.06 g |
| Height |
2.42 mm |
| Depth |
30 mm |
| Width |
22 mm |
| Technical details |
|---|
| Compliance certificates |
CB, UL |
| Logistics data |
|---|
| Harmonized System (HS) code |
8517620090 |
| Other features |
|---|
| Status |
Launched |
| Ethernet adapter ARK ID |
230079 |
| Export Control Classification Number (ECCN) |
5A991B |
| Supported Under vPro |
Yes |
