SKU: K35234EU

Kensington SD5920T EQ Thunderbolt 4 Quad 4K Hybrid Dock with DisplayLink Technology

Kensington
£227.10
  • Supports up to Quad 4K @ 60Hz for Thunderbolt™ 4 laptops and devices via plug-and-play TB4 port and MacBook* models with M1/M2/M3 Pro and Max chipsets via DisplayLink®. * For MacBook M1/M2/M3/M4 with Pro and Max chipsets (and M3 base chipset when laptop lid is closed), this dock supports up to quad 4K @ 60Hz. It also supports up to triple 4K @ 60Hz for M1/M2 base chipsets.
  • Optimised for Thunderbolt™ 4, Thunderbolt™ 3, USB4® and USB-C® devices running Windows (10 or later), macOS (11 or later) and ChromeOS (116 or later).
  • Composed of 100% post-consumer recycled (PCR) aluminium* and delivered in FSC® certified packaging. * The outer casing of the docking station is made of aluminium. The PCBA and any related inner components are not made of aluminium.
  • Combines Thunderbolt™ with DisplayLink® to provide next-level productivity experiences, including up to 40Gbps of data, video and audio, daisy chain support, together with Intel VT-d DMA protection.
  • Up to 100W Charging (96W certified) to power your laptop and connected accessories.
  • Productive 16-in-1 design allows users to work more efficiently and connect to a variety of setups.
  • Zero-footprint mounting option support a tidier workspace.
  • Security cable lock slots support device protection.
  • 3-Year limited warranty.

Supporting up to four external displays on laptops running Windows, macOS and ChromeOS, the SD5920T EQ Thunderbolt™ 4 Quad 4K Hybrid Dock with DisplayLink® Technology is a versatile docking station for unlocking the full potential of Thunderbolt™ 4, Thunderbolt™ 3, USB4® and USB-C® devices. Flexible video connections include 2 x HDMI®/DP ports, 1 x DP port and 1 x Thunderbolt™ 4 port, supporting up to Quad 4K @ 60Hz. Focused on productivity, the SD5920T supports up to 100W Charging (96W certified) to the laptop, 40Gbps data transfer speeds and includes 16 connectivity ports. Partially made with recycled materials. Includes security cable lock slots and 3-year limited warranty. * For MacBook M1/M2/M3/M4 with Pro and Max chipsets (and M3 base chipset when laptop lid is closed), this dock supports up to quad 4K @ 60Hz. It also supports up to triple 4K @ 60Hz for M1/M2 base chipsets.

Ports & interfaces
DC-in jack Yes
Headphone connectivity 3.5 mm
Headphone outputs 1
Combo headphone/mic port Yes
Thunderbolt 4 ports quantity 2
DisplayPorts quantity 3
HDMI ports quantity 2
USB Power Delivery revision 3.0
USB Power Delivery up to 96 W
USB Power Delivery (USB PD) Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
Host interface Thunderbolt 4
Connectivity technology Wired
Network
Ethernet LAN data rates 100,1000,2500 Mbit/s
Ethernet LAN (RJ-45) ports 1
Ethernet LAN Yes
Performance
Country of origin Vietnam
Plug and Play Yes
LED indicators Yes
Housing material Aluminium, Plastic
On/off switch Yes
Cable lock slot type Nano, Kensington
Cable lock slot Yes
Number of displays supported 4
Maximum digital resolution 7680 x 4320 pixels
HD type 8K Ultra HD
Data transfer rate 40 Gbit/s
Compatible memory cards SD, MicroSD (TransFlash)
Card reader integrated Yes
Product colour Black
Power
Output voltage 21 V
Output current 7.1 A
Input current 2.5 A
AC input voltage 100 - 240 V
Power source type DC
Software
Other operating systems supported ChromeOS
Mac operating systems supported Yes
Windows operating systems supported Yes
Operational conditions
Operating relative humidity (H-H) 0 - 55%
Storage temperature (T-T) -18 - 60 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Weight 600 g
Height 22 mm
Depth 85 mm
Width 2250 mm
Packaging data
Package weight 1.5 kg
Package height 94 mm
Package depth 107 mm
Package width 245 mm
Quantity per pack 1 pc(s)
Packaging content
Quick start guide Yes
Cables included AC, Thunderbolt
AC adapter included Yes
Technical details
Compliance certificates CB, CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA
Logistics data
Products per shipping (inner) case 6 pc(s)
Master (outer) case width 360 mm
Master (outer) case length 495 mm
Master (outer) case height 135 mm
Master (outer) case gross weight 9.63 kg
Other features
Compatible operating systems Chrome OS 116 or above; Windows 10 or above; macOS 11 or above
USB ports quantity 4
Special features EQ
