For high-speed, low-power storage needs
Kingston’s NV3 PCIe 4.0 NVMe SSDs are next-gen storage solutions powered by a Gen 4x4 NVMe controller, delivering read/write speeds of up to 6,000/5,000MB/s*. They come in both compact, single-sided M.2 2280 (22x80mm) and 2230 (22x30mm) sizes to expand storage in small-form-factor systems like laptops and handheld gaming consoles*****. They offer lower power consumption and reduced heat, optimising your system's performance without compromising value. Available in capacities from 500GB– 4TB** to give you all the space you need for applications, documents, photos, videos, games and more.
Gen 4x4 NVMe PCIe performance
Upgrade your system with read/write speeds up to 6,000/5,000MB/s*.
Small size, big performance
NV3 2280 and 2230 easily integrate into thin laptops and ultra-small PCs with M.2 connectors and limited space.
Increased storage space
Available in a variety of high capacities up to 4TB**, providing ample space to store files, videos, documents, and games with room to spare.
Store more, play more
With NV3 2230 upgrade compatible handheld gaming systems to get in the game faster*****.
Features |
TBW rating |
640 |
Mean time between failures (MTBF) |
200000 h |
PCI Express interface data lanes |
x4 |
Write speed |
5000 MB/s |
Read speed |
6000 MB/s |
M.2 SSD size |
2230 (22 x 30 mm) |
Component for |
Notebook/Game console |
Memory type |
3D NAND |
NVMe |
Yes |
Interface |
PCI Express 4.0 |
SSD form factor |
M.2 |
SSD capacity |
2 TB |
Weight & dimensions |
Weight |
2.8 g |
Height |
2.3 mm |
Depth |
22 mm |
Width |
30 mm |
Packaging data |
Package height |
114.3 mm |
Package depth |
8.13 mm |
Package width |
101.6 mm |
Operational conditions |
Non-operating vibration |
20 G |
Storage temperature (T-T) |
-40 - 85 °C |
Operating temperature (T-T) |
0 - 70 °C |
Logistics data |
Products per master (outer) case |
25 pc(s) |
Master (outer) case gross weight |
389.82 g |
Master (outer) case height |
114.3 mm |
Master (outer) case length |
171.4 mm |
Master (outer) case width |
120.7 mm |
Country of origin |
China, Taiwan |
