The Lindy USB Type C - HDMI 4K Video Capture Card allows you to capture and record video from an HDMI source device, such as a game console or camera, and transfer it to your USB Type-C equipped computer or device. The card supports 4K@30Hz recording resolutions and can be used for a variety of purposes such as live streaming, video production, and content creation. It also allows for real time monitoring of the HDMI source on the computer or device.
Please note: No software is provided with this capture device, 3rd party software must be used.
| Performance |
|---|
| Certification |
CE, UKCA, FCC, RoHS & REACH |
| Housing material |
Acrylonitrile butadiene styrene (ABS) |
| High Dynamic Range (HDR) supported |
Yes |
| Chipset |
EJ511 |
| Bandwidth |
18 Gbit/s |
| Video capture resolution (max) |
3840 x 2160 pixels |
| Host interface |
HDMI/USB 3.2 Gen 1 (3.1 Gen 1) |
| Internal |
No |
| Product colour |
Grey, Red |
| Ports & interfaces |
|---|
| HDMI version |
1.4b |
| Number of HDMI outputs |
1 |
| HDMI in |
1 |
| HDMI ports quantity |
2 |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| USB connector type |
USB Type-C |
| USB port |
Yes |
| Power |
|---|
| Power supply type |
USB |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
0 - 95% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating temperature (T-T) |
-10 - 40 °C |
| Technical details |
|---|
| Warranty period |
2 year(s) |
| Other features |
|---|
| Power requirements |
5VDC 1A |
| Weight & dimensions |
|---|
| Weight |
94 g |
| Height |
17 mm |
| Depth |
66 mm |
| Width |
130 mm |
| Packaging data |
|---|
| Package type |
Box |
| Package height |
174 mm |
| Package width |
103 mm |
| Package depth |
46 mm |
| Package weight |
201 g |
| Packaging content |
|---|
| Quantity |
1 |
| Manual |
Yes |
| Cables included |
USB Type-C to USB Type-C |
