2-in-1 Camera Solution
Twist the gooseneck to any angle to view a document, face the presenter or angle towards the class for a live video conference.
Excellent Image Quality
DC132U produces professional-quality images with vivid colors. It outputs 1080p or even 2K video with image and video recording up-to 30 frames per second. The DC132U is ideal for use in education and training.
One-touch Optimization (Auto-Tune)
At the touch of a button, the camera quickly achieves accurate focus, color balance and image exposure.
Imaging Flexibility
The camera can capture documents and objects larger than A3. Adjust the position of the camera for close-up or wide-angle imaging. Zoom into the image using the provided Ladibug software.
Macro Close-Up
Take extreme close-ups (4cm minimum distance) and capture detailed images of small objects such as insects.
Camera |
Light source |
LED |
Continuous shooting mode |
Yes |
Image freeze |
Yes |
Maximum frame rate |
30 fps |
Maximum video resolution |
2048 x 1536 pixels |
HD type |
Full HD |
Supported graphics resolutions |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1600 x 1200, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA) |
Sensor type |
CMOS |
Optical sensor size |
25.4 / 3 mm (1 / 3") |
Effective sensor resolution |
3.3 MP |
Lens system |
Shooting area (WxD) |
480 x 360 mm |
Digital zoom |
16x |
Optical zoom |
8x |
Auto focus |
Yes |
Ports & interfaces |
USB 2.0 ports quantity |
1 |
USB connector type |
USB Type-A |
Interface |
USB 2.0 |
Technical details |
Built-in microphone |
Yes |
Lamp type |
LED |
Photo effects |
Mirror |
Lamps quantity |
1 lamp(s) |
Bundled software |
Ladibug |
Image quality adjustment |
Sharpness |
Cable lock slot |
Yes |
Cable lock slot type |
Kensington |
Control type |
Buttons |
Product colour |
Black, Red |
Power |
USB powered |
Yes |
Power supply type |
USB |
Weight & dimensions |
Dimensions folded (WxDxH) |
106 x 136 x 280 mm |
Weight |
1.2 kg |
Height |
380 mm |
Depth |
350 mm |
Width |
106 mm |
