When true-to-life colour rendition is essential, the MA Series’ advanced feature set delivers calibrated precision, without compromise. For specialist applications, the wide colour gamut panel, SpectraView engine technology and 8K signal processing, positions the MA series at the high end of professional content delivery.
The MA series’ modular design includes Intel Smart Display Module (Intel SDM) technology integrated into the display, facilitating powerful media playback for the most intuitive signage creation and delivery. Featuring an integral audio amplifier, multi-picture mode technology and extensive connectivity including video out, the MA series offers versatile functionality for corporate signage and prestige retail applications.
| Display |
|---|
| Native refresh rate |
60 Hz |
| Horizontal scan range |
15 - 135 kHz |
| Vertical scan range |
23 - 76 Hz |
| Haze rate |
28% |
| Display diagonal (metric) |
124 cm |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Contrast ratio (typical) |
8000:1 |
| Response time |
8 ms |
| Native aspect ratio |
16:9 |
| HD type |
4K Ultra HD |
| Display brightness |
500 cd/m² |
| Display resolution |
3840 x 2160 pixels |
| LED backlighting type |
Edge-LED |
| LED backlight |
Yes |
| Panel type |
IPS |
| Display technology |
LCD |
| Display diagonal |
124.5 cm (49") |
| Ports & interfaces |
|---|
| RS-232 interface |
Yes |
| Audio (L/R) out |
1 |
| Ethernet LAN data rates |
100 Mbit/s |
| Ethernet LAN (RJ-45) ports |
2 |
| Ethernet LAN |
Yes |
| USB version |
2.0 |
| USB ports quantity |
3 |
| USB port |
Yes |
| DisplayPorts out |
1 |
| DisplayPorts in |
2 |
| DisplayPorts quantity |
3 |
| HDMI output ports quantity |
1 |
| HDMI input ports quantity |
2 |
| HDMI ports quantity |
3 |
| Design |
|---|
| Bezel width (top) |
1.2 cm |
| Bezel width (side) |
1.25 cm |
| Bezel width (bottom) |
1.56 cm |
| Panel mounting interface |
300 x 300 mm |
| VESA mounting |
Yes |
| Orientation |
Horizontal/Vertical |
| Placement supported |
Indoor |
| Product colour |
Black |
| Product design |
Digital signage flat panel |
| Performance |
|---|
| International Protection (IP) code |
IP5X, IP2X |
| HDCP |
Yes |
| Operating hours (hours/days) |
24/7 |
| Ambient light sensor |
Yes |
| Picture-in-Picture |
Yes |
| Purpose |
Universal |
| Power |
|---|
| AC input frequency |
50 - 60 Hz |
| AC input voltage |
100 - 240 V |
| Energy consumption (HDR) per 1000 hours |
95 kWh |
| Energy consumption (SDR) per 1000 hours |
102 kWh |
| Energy efficiency class (HDR) |
G |
| Energy efficiency class (SDR) |
G |
| Power consumption (off) |
0.5 W |
| Power consumption (standby) |
2 W |
| Power consumption (typical) |
85 W |
| Weight & dimensions |
|---|
| Display weight |
22.9 kg |
| Display height |
636.2 mm |
| Display depth |
61.1 mm |
| Display width |
1103.4 mm |
| Packaging data |
|---|
| Package volume |
29800 cm³ |
| Package height |
860 mm |
| Package depth |
203 mm |
| Package width |
1298 mm |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Operating temperature (T-T) |
0 - 40 °C |
| General |
|---|
| Product family |
MultiSync |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
| Technical details |
|---|
| Sustainability certificates |
ENERGY STAR |
