EASY POE CONTROLS
Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for advanced control over all PoE-powered devices
GIGABIT ETHERNET
5 ports provide gigabit Ethernet connectivity to your devices
VLANS
Port-based and 802.1Q-based network separation into smaller groups for more secure and efficient use of network resources
FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments
VERSATILE MOUNTING OPTIONS
Place your switch on your desktop or mount it to your wall with the hardware provided in the box. Silent operation makes this switch perfect for noise-sensitive environments
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
| Management features |
|---|
| Quality of Service (QoS) support |
Yes |
| Switch type |
Unmanaged |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
5 |
| Network |
|---|
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Flow control support |
Yes |
| Link aggregation |
Yes |
| Broadcast storm control |
Yes |
| Full duplex |
Yes |
| Port mirroring |
Yes |
| Copper ethernet cabling technology |
1000BASE-T, 100BASE-T, 10BASE-T |
| 10G support |
No |
| Networking standards |
IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az |
| Data transmission |
|---|
| Packet buffer memory |
1.5 MB |
| Jumbo frames |
9216 |
| Jumbo frames support |
Yes |
| Store-and-forward |
Yes |
| MAC address table |
2000 entries |
| Security |
|---|
| IGMP snooping |
Yes |
| DHCP features |
DHCP client |
| Multicast features |
|---|
| Multicast MAC address table |
4000 entries |
| Design |
|---|
| LED indicators |
Activity, Link, PoE, Power, Speed, Status |
| Housing material |
Metal |
| Product colour |
Grey |
| Form factor |
Desktop/Wall-Mounting |
| Stackable |
No |
| Rack mounting |
No |
| Performance |
|---|
| Mean time between failures (MTBF) |
842428 h |
| Fanless |
Yes |
| Power |
|---|
| Power consumption (max) |
141.4 W |
| Input current |
1.66 A |
| DC input voltage |
54 V |
| Power supply included |
No |
| Power source |
AC/DC |
| Power over Ethernet (PoE) |
|---|
| Total Power over Ethernet (PoE) budget |
123 W |
| Power over Ethernet (PoE) power per port |
30 W |
| Power over Ethernet (PoE) ports quantity |
4 |
| Power over Ethernet (PoE) |
Yes |
| Other features |
|---|
| Bandwidth |
10 Gbit/s |
| Operational conditions |
|---|
| Heat dissipation |
3.24 BTU/h |
| Operating altitude |
0 - 3000 m |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 90% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
400 g |
| Height |
27 mm |
| Depth |
101 mm |
| Width |
158 mm |
| Packaging content |
|---|
| Manual |
Yes |
| Quick start guide |
Yes |
| Certificates |
|---|
| Certification |
CB, CE LVD, CSA |
| Compliance certificates |
CB, CE, Federal Communications Commission (FCC) |
