RELIABLE PERFORMANCE
Superior network performance at non-blocking rate delivers true gigabit speed with no compromise
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
PLUG-AND-PLAY
No software to install. No configuration needed. Zero maintenance required
SILENT OPERATION
The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments
VERSATILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your wall with the hardware provided in the box
METAL CASE
Durable and rugged case for long-lasting performance
| Management features |
|---|
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2 |
| Switch type |
Unmanaged |
| Ports & interfaces |
|---|
| Power connector |
DC-in jack |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
16 |
| Network |
|---|
| Virtual LAN features |
Port-based VLAN |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Port mirroring |
Yes |
| Copper ethernet cabling technology |
1000BASE-T, 100BASE-TX, 10BASE-T |
| 10G support |
No |
| Networking standards |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Data transmission |
|---|
| Jumbo frames support |
Yes |
| Security |
|---|
| IGMP snooping |
Yes |
| Design |
|---|
| Electromagnetic compatibility |
CE mark (commercial), EN 55022 (CISPR 22) Class A, FCC Part 15 Class A, VCCI Class A, C-Tick |
| Safety |
CE/LVD, EN 60950, CB, CCC |
| Product colour |
Black |
| Rack mounting |
No |
| Performance |
|---|
| Compatible operating systems |
Microsoft Windows 7/Vista/XP |
| Power |
|---|
| Input voltage |
12 V |
| Input current |
1.5 A |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) |
No |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
0 - 90% |
| Operating temperature (T-T) |
0 - 50 °C |
| Weight & dimensions |
|---|
| Weight |
890 g |
| Height |
27 mm |
| Depth |
102 mm |
| Width |
286 mm |
| Packaging content |
|---|
| Manual |
Yes |
| User guide |
Yes |
| Quick start guide |
Yes |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
