POWER-OVER-ETHERNET
24 PoE+ ports delivering up to 30W per port with a 380W total power budget for wireless APs, IP Cameras, IP Phones and much more. Dynamic PoE maximizes usage of PoE budget.
PLUG-AND-PLAY
Simple set up with no software to install or configuration needed
NON-BLOCKING SWITCHING
Non-blocking switching architecture for maximum throughput at wire speed
DYNAMIC FANS
Optimal balance between noise and performance.
VERSATILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your rack with the hardware provided in the box
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
| Management features |
|---|
| MIB support |
RFC 1213 MIB II, RFC 1643, RFC 1493 |
| Quality of Service (QoS) support |
Yes |
| Switch type |
Unmanaged |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
48 |
| Network |
|---|
| Ethernet LAN data rates |
1000 Mbit/s |
| Flow control support |
Yes |
| Link aggregation |
Yes |
| Full duplex |
Yes |
| Copper ethernet cabling technology |
10BASE-T |
| Networking standards |
IEEE 802.1p, IEEE 802.3az |
| Data transmission |
|---|
| Packet buffer memory |
1.5 MB |
| Jumbo frames |
12.288 |
| Jumbo frames support |
Yes |
| Maximum data transfer rate |
1 Gbit/s |
| MAC address table |
8000 entries |
| Design |
|---|
| Safety |
CE mark, cUL IEC950/EN60950 |
| Number of fans |
2 fan(s) |
| Redundant fans support |
Yes |
| Product colour |
Grey |
| Rack mounting |
Yes |
| Performance |
|---|
| Mean time between failures (MTBF) |
570972 h |
| Power |
|---|
| Power consumption (max) |
410 W |
| Input current |
8 A |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power source |
AC/DC |
| Power over Ethernet (PoE) |
|---|
| Total Power over Ethernet (PoE) budget |
380 W |
| Power over Ethernet (PoE) power per port |
30 W |
| Power over Ethernet (PoE) |
Yes |
| Other features |
|---|
| I/O ports |
48 x 10/100/1000 Mbps4 x SFP |
| Electromagnetic emissions |
CE mark, FCC Part 15 Class A, VCCI Class A, C-Tick |
| Authentication method |
802.1x |
| Warranty period |
2 year(s) |
| Bandwidth |
96 Gbit/s |
| Connectivity technology |
Wired |
| Latency |
2,900ns |
| Operational conditions |
|---|
| Heat dissipation |
34.2 BTU/h |
| Operating altitude |
0 - 3000 m |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating temperature (T-T) |
0 - 50 °C |
| Weight & dimensions |
|---|
| Weight |
4.6 kg |
| Height |
43 mm |
| Depth |
310 mm |
| Width |
440 mm |
| Certificates |
|---|
| Compliance certificates |
CB, CE, Federal Communications Commission (FCC), KC, Low Voltage Directive (LVD), RCM, UL, VCCI |
