The P300 is Patriot’s next generation of mid-tier PCIe gen 3x4 NVMe SSD to hit the market, offering 25% higher transfer speeds and IOPs than standard PCIe 3x2 solutions. The compact m.2 form factor is designed for easy installation and will fit into any PC or laptop, while its low power consumption helps extend laptop battery life. The P300 is guaranteed to improve start-up, loading, and transfer times over traditional hard disk drives.
The P300’s advanced firmware offers ECC technology and end-to-end data path protection to ensure data integrity throughout the life to the drive. Advanced wear-leveling and thermal management features extend the life of the drive for maximum use.
Boost your computer’s performance with quicker application loading times for a better overall experience and productivity while transferring heavy workloads without the lag.
| Features |
|---|
| Certification |
CE, FCC |
| TBW rating |
320 |
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows 8.1 |
| End-to-End Data Protection |
Yes |
| ECC |
Yes |
| PCI Express interface data lanes |
x4 |
| Sequential write speed (CDM) |
1650 MB/s |
| Sequential read speed (CDM) |
2100 MB/s |
| Sequential write speed (ATTO) |
1650 MB/s |
| Sequential read speed (ATTO) |
2100 MB/s |
| Random write (4KB) |
260000 IOPS |
| Random read (4KB) |
290000 IOPS |
| Write speed |
1650 MB/s |
| Read speed |
2100 MB/s |
| Component for |
PC/Laptop |
| NVMe version |
1.3 |
| NVMe |
Yes |
| Interface |
PCI Express 3.0 |
| SSD form factor |
M.2 |
| SSD capacity |
2 TB |
| Power |
|---|
| Power consumption (idle) |
0.38 W |
| Weight & dimensions |
|---|
| Weight |
9 g |
| Height |
22 mm |
| Depth |
3.8 mm |
| Width |
80 mm |
| Packaging data |
|---|
| Package type |
Hanging box |
| Package weight |
20 g |
| Package height |
99.6 mm |
| Package depth |
6.6 mm |
| Package width |
130.8 mm |
| Operational conditions |
|---|
| Minimum operating temperature |
0 °C |
| Maximum operating temperature |
70 °C |
| Operating temperature (T-T) |
0 - 70 °C |
| Other features |
|---|
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Harmonized System (HS) code |
84717070 |
