PPDS Wave-ready for remote display management and control
Your PPDS Wave-ready display enables you to manage and maintain this device remotely, wherever you are, whenever you choose. This evolutionary cloud platform puts you fully in control, with simplified installation and setup, monitoring and controlling displays, upgrading firmware, managing central content needs and setting power schedules — saving you time, energy and environmental impact.
Built-in camera and speakers
The built-in camera and speakers make this small touchscreen a truly versatile smart solution. Use it for retail audience measurement, footfall analytics and more. Harness the power of Android AI apps to show targeted content. Or simply use your display for video conferencing.
Internal memory. Upload content for instant play
Save and play content without the need for a permanent external player. Your Philips Professional Display has an internal memory, which allows you to upload media into the display for instant playback. The internal memory also functions as a cache for online streaming.
Plug-and-play 10-point multi-touch display
Android-powered Philips professional displays are flexible and secure, optimised for native Android apps and the easy installation of web apps and software directly on the display. All controlled via an Internet connection.
Android: Run your own app or choose your favourite app to run
With Android OS integrated into the display, you can work with the most developed OS on the planet and save your own app directly into the display. Or, choose from the large library of Android apps and play content from there. With the built-in scheduler, you can daypart your apps and content based on your customer and time of day. With the auto-orientation feature, showing content in portrait or landscape is as simple as turning the display.
Near-Field Communication (NFC) for security
NFC (Near Field Communication) offers secure authentication and access control, enhancing security with encrypted data transfer. Its contactless operation minimises the risk of unauthorised access or data interception, ensuring reliable security of the displays.
| Display |
|---|
| Number of displays |
1 |
| Display diagonal (metric) |
25.6 cm |
| Display number of colours |
16.7 million colours |
| Viewing angle, vertical |
160° |
| Viewing angle, horizontal |
160° |
| Contrast ratio (typical) |
1000:1 |
| Response time |
35 ms |
| Native aspect ratio |
16:10 |
| Multi-touch |
Yes |
| Number of simultaneous touchpoints |
10 |
| Touchscreen technology |
Projected capacitive system |
| Touchscreen |
Yes |
| HD type |
WXGA |
| Display brightness |
350 cd/m² |
| Display resolution |
1280 x 800 pixels |
| Display technology |
LCD |
| Display diagonal |
25.6 cm (10.1") |
| Ports & interfaces |
|---|
| Compatible memory cards |
MicroSD (TransFlash) |
| Card reader integrated |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN |
Yes |
| USB connector type |
USB Type-A, USB Type-C |
| USB ports quantity |
3 |
| USB port |
Yes |
| DVI port |
No |
| HDMI output ports quantity |
1 |
| HDMI ports quantity |
1 |
| Audio |
|---|
| RMS rated power |
3 W |
| Number of built-in speakers |
2 |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Mounting type |
Wall |
| Bezel width (top) |
2.2 cm |
| Bezel width (side) |
2.2 cm |
| Bezel width (bottom) |
1.4 cm |
| Panel mounting interface |
75 x 75 mm |
| VESA mounting |
Yes |
| Screen shape |
Flat |
| Orientation |
Horizontal/Vertical |
| Placement supported |
Indoor |
| Product colour |
Black |
| Product design |
Digital signage flat panel |
| Performance |
|---|
| Operating hours (hours/days) |
24/7 |
| Number of OSD languages |
18 |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Arabic, Simplified Chinese, Traditional Chinese, Danish, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish |
| Purpose |
Commercial |
| Power |
|---|
| Power consumption (max) |
18 W |
| Power consumption (standby) |
0.5 W |
| Input voltage |
12 V |
| Power consumption (typical) |
4 W |
| Computer system |
|---|
| Operating system version |
13 |
| Operating system installed |
Android |
| Internal storage capacity |
16 GB |
| Internal memory |
2 GB |
| Processor model |
RK3568 |
| Processor manufacturer |
Rockchip |
| Built-in processor |
Yes |
| Computer system |
Yes |
| Weight & dimensions |
|---|
| Display weight |
800 g |
| Display height |
164 mm |
| Display depth |
24.8 mm |
| Display width |
262 mm |
| Packaging content |
|---|
| Cables included |
HDMI, USB Type-A to USB Type-C |
| Power adapter included |
Yes |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
10 - 85% |
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
30 - 80% |
| Operating temperature (T-T) |
0 - 40 °C |
| General |
|---|
| Product family |
Signage Solutions |
| Technical details |
|---|
| Compliance certificates |
CB, CE, ETL, Federal Communications Commission (FCC), RoHS |
| Warranty period |
3 year(s) |
| Other features |
|---|
| Bluetooth version |
5.0 |
| Bluetooth |
Yes |
