There is a standard 10M lead to connect to your projector to automate the screen drop and retraction via 12V trigger. This product also has built in RS232 and zero volt contact closure so you can control the screen with a control system. There is an optional zero voltage wall switch.
This screen comes with a 2.7m power lead from the back left of the screen (when viewed from the front) and terminates in a standard UK power plug.
Fabric specifications:
Sapphire's matt white fabric is composed of triple ply fibreglass laminate which helps prevent wrinkles and waves. The screen fabric consists of a special material that helps prevent the loss of light, making it compatible with non short throw projectors. Our screen fabrics are designed to be fire, water, and mould resistant and can be cleaned if necessary. The top layer of the fabric has microdots that are made with PVC technology that helps create the best possible reflection.
The 1.1 gain reflects the same amount of light back that the projector produces achieving a true cinema experience.
The back of the fabric is completely black enabling you to put this in front of a window.
Performance |
Viewable screen width (W) |
127.3 cm |
Viewable screen height (H) |
2.04 m |
Native aspect ratio |
16:10 |
Design |
Material |
Aluminium |
Case colour |
White |
Product colour |
White |
Easy to install |
Yes |
Black drop |
45 cm |
Borders |
Yes |
Black backing |
Yes |
Mounting type |
Wall |
Power |
Input current |
0.45 A |
Input frequency |
230 Hz |
Power |
103.5 W |
Weight & dimensions |
Dimensions folded (WxDxH) |
2354 x 79 x 93 mm |
Weight |
12 kg |
Height |
93 mm |
Depth |
79 mm |
Width |
2354 mm |
Packaging data |
Package weight |
14.5 kg |
Package height |
155 mm |
Package depth |
160 mm |
Package width |
2591 mm |
Quantity per pack |
1 pc(s) |
Certificates |
Waste Electrical and Electronic Equipment (WEEE) compliance |
Yes |
UN number |
WW/BA0104WV |
Battery |
Battery weight |
11.5 g |
Number of battery cells |
2 |
Packaging content |
Batteries included |
Yes |
Remote control included |
Yes |
Logistics data |
Products per shipping (inner) case |
1 pc(s) |
Shipping (inner) case height |
15.5 cm |
Shipping (inner) case length |
2.59 m |
Shipping (inner) case width |
16 cm |
Harmonized System (HS) code |
90106000 |
Master (outer) case gross weight |
14.5 kg |
Master (outer) case length |
2591 mm |
Master (outer) case width |
160 mm |
Master (outer) case height |
155 mm |
Products per pallet |
36 pc(s) |
Pallet gross weight |
522 kg |
Pallet gross length |
2.59 m |
Pallet gross width |
100 cm |
Pallet gross height |
120 cm |
Minimum order quantity |
1 pc(s) |
Products per master (outer) case |
1 pc(s) |
Products per pallet layer |
6 pc(s) |
Products per pallet layer (UK) |
6 pc(s) |
Products per pallet (UK) |
36 pc(s) |
Pallet weight (UK) |
522 kg |
Pallet length (UK) |
2.59 m |
Pallet height (UK) |
120 cm |
