SkyHawk™ leverages Seagate's extensive experience in designing drives purpose-built for surveillance applications.
ImagePerfect™ firmware is designed to ensure seamless video footage capture in 24×7 surveillance workloads1 that record video from 64 HD cameras.
SkyHawk Health Management actively helps protect your surveillance storage by focusing on prevention, intervention, and recovery options.2 Included is RAID RapidRebuild™, which provides 3× faster volume rebuilds over traditional RAID rebuilds.
Unparalleled data protection with included 3-year Rescue Data Recovery Services plan, helping protect important video data with Seagate's in-house data recovery services.
RV sensors built in allow drives to maintain performance in multi-bay systems, giving customers the flexibility to scale their systems when more storage is needed.
ATA streaming support enables recordings from up to 64 HD cameras for smooth, uninterrupted footage.
1 M hours MTBF, 3-year limited warranty represents an improved total cost of ownership (TCO) with reduced maintenance costs.
Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions. Tarnish-resistant components help protect drive from environmental elements, increasing field reliability
Features |
Mean time between failures (MTBF) |
1000000 h |
Workload rate limit |
180 TB/year |
Start/stop cycles |
600000 |
RV sensor(s) |
Yes |
24/7 operation |
Yes |
Rotational Vibration (RV) sensors |
Yes |
Uncorrectable Bit Error Rate (UBER) |
< 1 per 10^14 bits read |
HDD sustained transfer rate |
180 MiB/s |
HDD interface transfer rate |
6 Gbit/s |
Storage drive buffer size |
256 MB |
Component for |
PC |
Type |
HDD |
Interface |
Serial ATA III |
HDD size |
3.5" |
HDD capacity |
6 TB |
Power |
Start-up current |
1.8 A |
Operating voltage |
5 / 12 V |
Power consumption (idle) |
3.4 W |
Power consumption (off) |
0.25 W |
Power consumption (typical) |
5.3 W |
Operational conditions |
Operating temperature (T-T) |
0 - 65 °C |
General |
Product family |
SkyHawk |
Weight & dimensions |
Weight |
630 g |
Height |
26.1 mm |
Depth |
147 mm |
Width |
101.6 mm |
Other features |
Maximum number of cameras supported |
64 |
