Professional performance, affordable value
The entry point for professional display solutions, the Sharp MultiSync® E9 Series is designed for modern business environments that need more than a consumer TV can offer. Combining essential features for meeting rooms and digital signage with commercial-grade reliability, the E9 Series delivers crisp UHD resolution, integrated media playback, and 16/7 operation at an accessible price point. A professional matte high-haze panel ensures superior visual performance in this product category, minimising reflections and glare common with glossy panels.
Designed for seamless integration across the wider Sharp display family, the E9 Series shares the same core identity, including the same remote control and device management for a consistent user experience. A robust metal back cover secures product longevity in commercial settings. Whether for presentations, retail signage, or corporate communication, the E9 Series gives you the professional edge without stretching your budget
| Display |
|---|
| Horizontal scan range |
31.5 - 135 kHz |
| Vertical scan range |
24 - 75 Hz |
| Haze rate |
25% |
| Display diagonal (metric) |
189.3 cm |
| Active display area (W x H) |
1650 x 928 mm |
| Pixel pitch |
0.43 x 0.43 mm |
| Display number of colours |
1.073 billion colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Contrast ratio (typical) |
1200:1 |
| Response time |
8 ms |
| Native aspect ratio |
16:9 |
| Touchscreen |
No |
| HD type |
4K Ultra HD |
| Display brightness |
350 cd/m² |
| Display resolution |
3840 x 2160 pixels |
| LED backlighting type |
Direct-LED |
| LED backlight |
Yes |
| Panel type |
IPS |
| Display technology |
LCD |
| Display diagonal |
190.5 cm (75") |
| Ports & interfaces |
|---|
| RS-232C |
Yes |
| PC Audio in |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
100 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN |
Yes |
| USB connector type |
USB Type-A, USB Type-C |
| USB version |
2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity |
4 |
| USB port |
Yes |
| DVI port |
No |
| HDMI output ports quantity |
2 |
| HDMI input ports quantity |
2 |
| HDMI ports quantity |
4 |
| Audio |
|---|
| RMS rated power |
20 W |
| Number of built-in speakers |
2 |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Mounting type |
Wall |
| Bezel width (top) |
1.29 cm |
| Bezel width (side) |
1.29 cm |
| Bezel width (bottom) |
1.29 cm |
| Panel mounting interface |
600 x 400 mm |
| VESA mounting |
Yes |
| Placement supported |
Indoor |
| Product colour |
Black |
| Product design |
Digital signage flat panel |
| Performance |
|---|
| Purpose |
Universal |
| Power |
|---|
| Energy efficiency scale |
A to G |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power consumption (sleep) |
0.5 W |
| Power consumption (standby) |
2 W |
| Power consumption (typical) |
170 W |
| Weight & dimensions |
|---|
| Display weight |
24 kg |
| Display height |
959 mm |
| Display depth |
58.5 mm |
| Display width |
1680 mm |
| Packaging data |
|---|
| Package weight |
33 kg |
| Package height |
1130 mm |
| Package depth |
186 mm |
| Package width |
1875 mm |
| Packaging content |
|---|
| Cables included |
AC |
| Batteries included |
Yes |
| Remote control included |
Yes |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
10 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Operating temperature (T-T) |
0 - 40 °C |
| General |
|---|
| Product family |
MultiSync |
