StarTech.com 1 Port PCI Express PCIe Gigabit NIC Server Adapter Network Card - Low Profile

SKU: ST1000SPEX2L
£28.42 inc. VAT
  • Wired
  • PCI Express Ethernet
  • 1000 Mbit/s 10/100/1000BaseT(X)
  • Internal Chipset: Realtek - RTL8111H

Add a 10/100/1000Mbps Ethernet port to any PC through a PCI Express slot

The ST1000SPEX2L Low-Profile PCIe Gigabit Network Card adds a 10/100/1000 Mbps compatible RJ45 Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or replacement networking interface.

Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging and Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter offers effective network performance.

The card comes pre-configured with a low-profile/half-height installation bracket and includes a standard profile bracket for installation in a wide range of computer/server chassis, regardless of form factor.

Backed by a 2-year StarTech.com warranty and free lifetime technical support.

The StarTech.com Advantage

- Optimize network traffic with support for advanced features such as Jumbo Frames and VLAN tagging
- Saves the time of having to adjust the mounting bracket, with a pre-configured half-height/low-profile bracket

Ports & interfaces
Interface Ethernet
Host interface PCI Express
Connectivity technology Wired
Network
Supported network protocols CSMA/CD
Jumbo frames support Yes
Jumbo frames 9000
Full duplex Yes
Auto MDIX IEEE Yes
Cabling technology 10/100/1000BaseT(X)
Ethernet LAN data rates 10,100,1000 Mbit/s
Ethernet LAN Yes
Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Maximum data transfer rate 1000 Mbit/s
Design
Certification CE, FCC, REACH
LED indicators Activity, Link
Chipset Realtek - RTL8111H
Internal Yes
System requirements
Server operating systems supported Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Linux operating systems supported Yes
Mac operating systems supported Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) 0 - 100 °C
Operating temperature (T-T) 0 - 70 °C
Weight & dimensions
Weight 27 g
Height 49 mm
Depth 70 mm
Width 18 mm
Packaging data
Package weight 125 g
Package height 31 mm
Package depth 144 mm
Package width 173 mm
Packaging content
Manual Yes
Technical details
Compliance certificates RoHS
Logistics data
Harmonized System (HS) code 85176990
Other features
Link/Act LED Yes
Power LED Yes
