Share a mouse, keyboard, USB 5Gbps Hub, and 8K 60Hz DisplayPort between two DisplayPort enabled computers
Share and switch between two USB-A and DisplayPort-enabled computers, using this DisplayPort KVM Switch. Share an 8K 60Hz DisplayPort monitor, a keyboard and mouse, two USB 5Gbps devices, and two additional USB 2.0 devices.
High-Resolution 8K 60Hz Video
This KVM supports resolutions up to 8K 60Hz or 4K 144Hz/120Hz. Daisy chain additional monitors via MST pass-through. The KVM supports ultrawide resolutions of up to 5120x1440 at 60Hz. Ideal for applications such as CAD/CAM, video editing, and content creation. Support for High Dynamic Range (HDR) offers increased contrast, brightness, colors, and greater luminosity.
Customizable Switching
This Universal KVM Switch provides various switching options, including hotkey or push-button switching. Hotkeys allow for independent switching of audio and video, enabling audio playback from one computer while controlling the other. An audible buzzer confirms hotkey input, and LEDs provide a visual status of the selected host.
Universal Compatibility
The TAA-Compliant KVM Switch offers universal compatibility, working with all operating systems, including Windows, macOS, ChromeOS, and Linux. It is also compatible with all hardware platforms, including Intel and AMD.
Reliable Performance
The durable metal housing helps prevent Electro-magnetic Interference (EMI). Overcurrent Protection (OCP) ensures peripherals don't overdraw power, reducing the occurrence of device dropouts or shutdowns.
The StarTech.com Advantage
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| Headphone outputs |
3 |
| Audio connections |
Yes |
| Console DisplayPorts ports quantity |
1 |
| Console ports |
3.5mm headphone, DisplayPort, USB A |
| Console USB ports quantity |
6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity |
2 |
| DisplayPort version |
1.4 |
| DisplayPorts quantity |
2 |
| Video port type |
DisplayPort |
| Mouse port type |
USB |
| Keyboard port type |
USB |
| Number of computers controlled |
2 |
| Performance |
|---|
| HDCP version |
1.4/2.2 |
| Chipset |
GL-3523 |
| Daisy chain |
No |
| Plug and Play |
Yes |
| HDCP |
Yes |
| High Dynamic Range (HDR) supported |
Yes |
| Scan interval |
3,8,15,30 s |
| Data transfer rate (max) |
5 Gbit/s |
| Maximum resolution |
7680 x 4320 pixels |
| HD type |
8K Ultra HD |
| Design |
|---|
| Mean time between failures (MTBF) |
130000 h |
| Hot keys |
Yes |
| Push button |
Yes |
| LED indicators |
Yes |
| Housing material |
Steel |
| Product colour |
Black |
| Rack mounting |
No |
| Display |
|---|
| On Screen Display (OSD) |
No |
| Built-in display |
No |
| Power |
|---|
| Power consumption (typical) |
36 W |
| Compatible power plug types |
EU, JP, UK, US |
| Output current |
3 A |
| Output voltage |
12 V |
| Input current |
1 A |
| Input voltage |
100 - 240 V |
| Power source |
DC |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, RoHS, Trade Agreements Act (TAA) |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
0 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
600 g |
| Height |
40 mm |
| Depth |
160 mm |
| Width |
100 mm |
| Packaging data |
|---|
| Package weight |
1 kg |
| Package height |
89 mm |
| Package depth |
184 mm |
| Package width |
238 mm |
| Packaging content |
|---|
| Rubber feet |
Yes |
| Quick installation guide |
Yes |
| Other features |
|---|
| IP control |
No |
| Logistics data |
|---|
| Master (outer) case height |
300 mm |
| Master (outer) case length |
257 mm |
| Master (outer) case width |
397 mm |
