Connect and hot swap four 3.5in SATA III or SAS II hard drives to your computer system in three 5.25” bays, with support for transfer speeds up to 6 Gbps
The HSB4SATSASBA Removable 4-drive Backplane makes inserting and removing drives fast and easy, by turning three 5.25" bays into a hot-swappable interface for up to four 3.5” SATA or SAS hard drives (HDD).
For added versatility, the hot swap bay can interface with SATA I/II/III and SAS I/II hard drives -- an ideal solution for enterprise system applications.
For a quick and secure method of installing and removing drives, the backplane features ejection levers and a key-lock design. To help prevent drive failure, the bay provides drive cooling with a built-in fan and excellent heat dissipation with a vented aluminum enclosure.
The HSB4SATSASBA is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
| Features |
|---|
| Certification |
CE, FCC |
| Number of fans |
1 fan(s) |
| Fan diameter |
7 cm |
| Data transfer rate |
6 Gbit/s |
| LED indicators |
Activity, Power |
| Key lock |
Yes |
| Hot-swap |
Yes |
| Material |
Aluminium |
| Product colour |
Black |
| Ports & interfaces |
|---|
| External SATA ports quantity |
4 |
| Weight & dimensions |
|---|
| Width |
145 mm |
| Depth |
197 mm |
| Height |
124 mm |
| Weight |
1.3 kg |
| Packaging data |
|---|
| Package weight |
1.59 kg |
| Package depth |
164 mm |
| Package height |
180 mm |
| Package width |
254 mm |
| Packaging content |
|---|
| Screws included |
Yes |
| Cables included |
SATA |
| Manual |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 55 °C |
| Operating relative humidity (H-H) |
5 - 85% |
| Storage temperature (T-T) |
-20 - 65 °C |
| Technical details |
|---|
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Harmonized System (HS) code |
84733080 |
| Products per master (outer) case |
6 pc(s) |
| Master (outer) case width |
385 mm |
| Master (outer) case length |
516 mm |
| Master (outer) case height |
281 mm |
