External SSD/HDD Docking Station | USB 3.2 Gen 2 (10 Gbps) to SATA I/II/III
This 4-bay SATA HDD docking station lets you access up to four solid-state drives or hard drives simultaneously over USB 10Gbps, and hot swap drives with ease. Ideal for IT professionals, the docking station provides large data capacity and fast file transfers, helping you manage your workflow more efficiently.
Save time accessing and managing your data
When you're managing a large number of drives, the HDD/SSD docking station saves you time. Quickly dock and swap your drives for disk imaging, data recovery from failing drives, data backups, or other tasks.
The hard drive docking station also has SMART support, for accessing important drive information such as hours in use, number of power cycles, and disk health.
Fast data transfers
With USB 3.2 Gen 2, the HDD docking station lets you leverage the high performance of the latest SSDs and hard drives, while alleviating bottlenecks in your data transfers.
Convenient compatibility
The hard drive docking station includes a USB Type-C cable, for connecting to USB-C equipped laptops and devices, and a USB Type-A cable, for backward compatibility with your existing USB 3.0, 2.0 and 1.x devices.
The docking station also works with 2.5" and 3.5" IDE hard drives, mSATA drives and M.2 drives using a compatible StarTech.com adapter:
IDE hard drives: Use StarTech.com adapter SAT2IDEADP SATA to 2.5in or 3.5in IDE Hard Drive Adapter for HDD Docks
mSATA drives: Use StarTech.com adapter SAT32MSAT257 mSATA SSD to 2.5in SATA Adapter Converter
M.2 drives: Use StarTech.com adapter SAT32M225 M.2 NGFF SSD to 2.5in SATA Adapter Converter
| Hard drive |
|---|
| Maximum storage capacity |
10 TB |
| Number of storage drives supported |
4 |
| Storage drive sizes supported |
2.5,3.5" |
| Storage drive interface |
Serial ATA, Serial ATA II, Serial ATA III |
| Storage media type |
HDD, SSD |
| Ports & interfaces |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) ports quantity |
1 |
| Host interface |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| Features |
|---|
| LED indicators |
Activity, Power |
| UASP support |
Yes |
| Number of connectivity cycles |
10000 |
| S.M.A.R.T. support |
Yes |
| TRIM support |
Yes |
| Hot-swap |
Yes |
| Plug and Play |
Yes |
| Maximum data transfer rate |
10 Gbit/s |
| Material |
Plastic |
| Product colour |
Black |
| Cooling |
|---|
| Bearing type |
Sleeve bearing |
| Fan diameter |
6 cm |
| Number of fans |
2 fan(s) |
| Built-in fan |
Yes |
| Power |
|---|
| Output current |
6.5 A |
| Output voltage |
12 V |
| Input current |
2 A |
| AC input voltage |
100 - 240 V |
| Power consumption (standby) |
78 W |
| Weight & dimensions |
|---|
| Weight |
1 kg |
| Height |
87 mm |
| Depth |
291 mm |
| Width |
171 mm |
| Packaging data |
|---|
| Package weight |
2.4 kg |
| Package height |
210 mm |
| Package depth |
340 mm |
| Package width |
170 mm |
| Packaging content |
|---|
| Quick installation guide |
Yes |
| Included power plug types |
ANZ, EU, JP, NA, UK |
| Cables included |
USB, USB Type-C |
| AC adapter included |
Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 50 °C |
| Operating temperature (T-T) |
5 - 35 °C |
| Other features |
|---|
| Mean time between failures (MTBF) |
30000 h |
| Chipset |
VIA Labs - VL820, VIA Labs - VL715 |
| Compliance certificates |
CE, RoHS |
| Noise level |
19.04 dB |
| Logistics data |
|---|
| Products per master (outer) case |
4 pc(s) |
| Master (outer) case height |
470 mm |
| Master (outer) case length |
356 mm |
| Master (outer) case width |
354 mm |
| Harmonized System (HS) code |
84733080 |
